  • For use with shell mill adaptors; please order separately.
  • Bridge body shipped without insert holder, slides, or micro-adjustable cartridges.
  • Order insert holder separately for rough boring and slides for fine boring.
  • Order micro-adjustable cartridges separately for fine boring.

L1 Assy L1 Assy L1 Assy = L1 bridge + L1 insert holder L1 Assy = L1 bridge + L1 slide + L1 cartridge

  • Bridge Tool Small

order number catalogue number BR1 bore range D L1 kg

order numbercatalogue numberBR1 bore rangeDL1kg
20060191260020880087.000-110.0002740,31,70
200550012600210900109.000-133.0002740,31,90
200555312600213200132.000-156.0002740,32,10
200555612600215500155.000-179.0002740,32,30
200556012600217800178.000-202.0002740,32,50
  • Spare Parts
fixingfixingfixingdisc disc
catalogue numberscrewscrewscrewwasherwasher
catalogue numberfixing screwfixing screwfixing screwdisc washerdisc washer
12600208800—123462330001214751910012147600300—
1260021090012147613500—121475191001214760030012147740200
1260021320012147613500—121475191001214760030012147740200
1260021550012147613500—121475191001214760030012147740200
1260021780012147613500—121475191001214760030012147740200
