TiAlN TiN
Seat Size 3
| �first choice | |||||
| D1 | L | S �alternate choice | |||
| TiAlN TiAlN | TiN TiN | D1 | L | S | |
| order # catalogue # | order # catalogue # | mm | mm | mm | � |
| — | 2760079 7F3-1391T | 35,32 | 20,45 | 6,35 | 132° |
| 2760078 7F3-1406A | 2760076 7F3-1406T | 35,72 | 20,45 | 6,35 | 132° |
| 2760072 7F3-1417A | 2760069 7F3-1417T | 36,00 | 20,45 | 6,35 | 132° |
| 2760066 7F3-1438A | 2760063 7F3-1438T | 36,51 | 20,45 | 6,35 | 132° |
| 2760060 7F3-1457A | 2760059 7F3-1457T | 37,00 | 20,45 | 6,35 | 132° |
| 2760058 7F3-1469A | 2760056 7F3-1469T | 37,31 | 20,45 | 6,35 | 132° |
| — | 2760053 7F3-1484T | 37,70 | 20,45 | 6,35 | 132° |
| 2760051 7F3-1496A | — | 38,00 | 20,45 | 6,35 | 132° |
| 2760048 7F3-1500A | 2760045 7F3-1500T | 38,10 | 20,45 | 6,35 | 132° |
| — | 2760038 7F3-1516T | 38,50 | 20,45 | 6,35 | 132° |
| — | 2760035 7F3-1531T | 38,90 | 20,45 | 6,35 | 132° |
| 2760034 7F3-1535A | — | 39,00 | 20,45 | 6,35 | 132° |
| 2760027 7F3-1563A | 2760024 7F3-1563T | 39,69 | 20,45 | 6,35 | 132° |
| 2760023 7F3-1575A | 2760021 7F3-1575T | 40,00 | 20,45 | 6,35 | 132° |
| — | 2760015 7F3-1594T | 40,48 | 20,45 | 6,35 | 132° |
| 2760011 7F3-1614A | — | 41,00 | 20,45 | 6,35 | 132° |
| 2760008 7F3-1625A | 2760004 7F3-1625T | 41,28 | 20,45 | 6,35 | 132° |
| 2760001 7F3-1654A | — | 42,00 | 20,45 | 6,35 | 132° |
| — | 2759996 7F3-1656T | 42,07 | 20,45 | 6,35 | 132° |
| 2759993 7F3-1688A | 2759991 7F3-1688T | 42,86 | 20,45 | 6,35 | 132° |
| — | 2759989 7F3-1693T | 43,00 | 20,45 | 6,35 | 132° |
| 2759987 7F3-1719A | 2759985 7F3-1719T | 43,66 | 20,45 | 6,35 | 132° |
| 2759984 7F3-1732A | — | 44,00 | 20,45 | 6,35 | 132° |
| 2759977 7F3-1750A | 2759974 7F3-1750T | 44,45 | 20,45 | 6,35 | 132° |
| — | 2759970 7F3-1766T | 44,85 | 20,45 | 6,35 | 132° |
| 2759969 7F3-1772A | 2759967 7F3-1772T | 45,00 | 20,45 | 6,35 | 132° |
| — | 2759963 7F3-1781T | 45,25 | 20,45 | 6,35 | 132° |
| 2759960 7F3-1811A | — | 46,00 | 20,45 | 6,35 | 132° |
| 2759958 7F3-1813A | 2759956 7F3-1813T | 46,04 | 20,45 | 6,35 | 132° |
| — | 2759951 7F3-1844T | 46,83 | 20,45 | 6,35 | 132° |
| — | 2759949 7F3-1850T | 47,00 | 20,45 | 6,35 | 132° |
| 2759945 7F3-1875A | 2759942 7F3-1875T | 47,63 | 20,45 | 6,35 | 132° |
