(VDS201A • VDS401A • 3 x D — continued)
| D1 dia | meter | �fir �alt | ist choice ernate cho | ice | |||||
| VDS201A • WU25PD VDS40 grade WU25PD TiAlN grad | 1A • WU25PD e WU25PD TiAlN | ||||||||
| order # catalogue # order # | catalogue # | mm | in | L4 max | L3 | L5 | L | LS | D |
| 4144539 VDS201A02400 4140431 | VDS401A02400 | 2,400 | .0945 | 12 | 17 | 0,4 | 58 | 28 | 4 |
| 4144540 VDS201A02439 4140432 | VDS401A02439 | 2,439 | .0960 | 12 | 17 | 0,4 | 58 | 28 | 4 |
| 4144541 VDS201A02489 4140433 | VDS401A02489 | 2,489 | .0980 | 12 | 17 | 0,4 | 58 | 28 | 4 |
| 4144542 VDS201A02500 4140434 | VDS401A02500 | 2,500 | .0984 | 12 | 17 | 0,4 | 58 | 28 | 4 |
| 4144543 VDS201A02578 4140435 | VDS401A02578 | 2,578 | .1015 | 12 | 17 | 0,4 | 58 | 28 | 4 |
| 4144544 VDS201A02600 4140436 | VDS401A02600 | 2,600 | .1024 | 12 | 17 | 0,4 | 58 | 28 | 4 |
| 4144545 VDS201A02642 4140437 | VDS401A02642 | 2,642 | .1040 | 12 | 17 | 0,4 | 58 | 28 | 4 |
| 4144546 VDS201A02700 4140438 | VDS401A02700 | 2,700 | .1063 | 12 | 17 | 0,4 | 58 | 28 | 4 |
| 4144547 VDS201A02705 4140439 | VDS401A02705 | 2,705 | .1065 | 12 | 17 | 0,4 | 58 | 28 | 4 |
| 4144548 VDS201A02779 4140440 | VDS401A02779 | 2,779 | .1094 | 12 | 17 | 0,4 | 58 | 28 | 4 |
| 4144549 VDS201A02800 4140441 | VDS401A02800 | 2,800 | .1102 | 12 | 17 | 0,5 | 58 | 28 | 4 |
| 4144550 VDS201A02820 4140442 | VDS401A02820 | 2,820 | .1110 | 12 | 17 | 0,5 | 58 | 28 | 4 |
| 4144551 VDS201A02870 4140443 | VDS401A02870 | 2,870 | .1130 | 12 | 17 | 0,5 | 58 | 28 | 4 |
| 4144552 VDS201A02900 4140444 | VDS401A02900 | 2,900 | .1142 | 12 | 17 | 0,5 | 58 | 28 | 4 |
| 4144553 VDS201A02947 4140445 | VDS401A02947 | 2,947 | .1160 | 12 | 17 | 0,5 | 58 | 28 | 4 |
| 4143907 VDS201A03000 4140299 | VDS401A03000 | 3,000 | .1181 | 14 | 20 | 0,5 | 62 | 36 | 6 |
| 4143908 VDS201A03048 4140300 | VDS401A03048 | 3,048 | .1200 | 14 | 20 | 0,5 | 62 | 36 | 6 |
| 4143909 VDS201A03100 4140301 | VDS401A03100 | 3,100 | .1220 | 14 | 20 | 0,5 | 62 | 36 | 6 |
| 4143910 VDS201A03175 4140302 | VDS401A03175 | 3,175 | .1250 | 14 | 20 | 0,5 | 62 | 36 | 6 |
| 4143911 VDS201A03200 4140303 | VDS401A03200 | 3,200 | .1260 | 14 | 20 | 0,5 | 62 | 36 | 6 |
| 4143912 VDS201A03264 4140304 | VDS401A03264 | 3,264 | .1285 | 14 | 20 | 0,5 | 62 | 36 | 6 |
| 4143913 VDS201A03300 4140305 | VDS401A03300 | 3,300 | .1299 | 14 | 20 | 0,5 | 62 | 36 | 6 |
| 4143914 VDS201A03400 4140306 | VDS401A03400 | 3,400 | .1339 | 14 | 20 | 0,6 | 62 | 36 | 6 |
| 4143915 VDS201A03455 4140307 | VDS401A03455 | 3,455 | .1360 | 14 | 20 | 0,6 | 62 | 36 | 6 |
| 4143916 VDS201A03500 4140308 | VDS401A03500 | 3,500 | .1378 | 14 | 20 | 0,6 | 62 | 36 | 6 |
| 4143917 VDS201A03571 4140309 | VDS401A03571 | 3,571 | .1406 | 14 | 20 | 0,6 | 62 | 36 | 6 |
| 4143918 VDS201A03600 4140310 | VDS401A03600 | 3,600 | .1417 | 14 | 20 | 0,6 | 62 | 36 | 6 |
| 4143919 VDS201A03658 4140311 | VDS401A03658 | 3,658 | .1440 | 14 | 20 | 0,6 | 62 | 36 | 6 |
| 4143920 VDS201A03700 4140312 | VDS401A03700 | 3,700 | .1457 | 14 | 20 | 0,6 | 62 | 36 | 6 |
| 4143921 VDS201A03734 4140313 | VDS401A03734 | 3,734 | .1470 | 14 | 20 | 0,6 | 62 | 36 | 6 |
| 4143922 VDS201A03800 4140314 | VDS401A03800 | 3,800 | .1496 | 17 | 24 | 0,6 | 66 | 36 | 6 |
| 4143923 VDS201A03900 4140315 | VDS401A03900 | 3,900 | .1535 | 17 | 24 | 0,6 | 66 | 36 | 6 |
| 4143924 VDS201A03970 4140316 | VDS401A03970 | 3,970 | .1563 | 17 | 24 | 0,7 | 66 | 36 | 6 |
| 4143925 VDS201A04000 4140317 | VDS401A04000 | 4,000 | .1575 | 17 | 24 | 0,7 | 66 | 36 | 6 |
| 4143926 VDS201A04039 4140318 | VDS401A04039 | 4,039 | .1590 | 17 | 24 | 0,7 | 66 | 36 | 6 |
| 4143927 VDS201A04090 4140319 | VDS401A04090 | 4,090 | .1610 | 17 | 24 | 0,7 | 66 | 36 | 6 |
| 4143928 VDS201A04100 4140320 | VDS401A04100 | 4,100 | .1614 | 17 | 24 | 0,7 | 66 | 36 | 6 |
| 4143929 VDS201A04200 4140321 | VDS401A04200 | 4,200 | .1654 | 17 | 24 | 0,7 | 66 | 36 | 6 |
| 4143930 VDS201A04217 4140322 | VDS401A04217 | 4,217 | .1660 | 17 | 24 | 0,7 | 66 | 36 | 6 |
| 4143931 VDS201A04300 4140323 | VDS401A04300 | 4,300 | .1693 | 17 | 24 | 0,7 | 66 | 36 | 6 (continued) |
