30° POS 15° 2
LF APMX DCON M2MB 3xD TOLERANCES DC (mm) RE 0,1–3,0 DIAMETER METRIC SERIES DC = +0,0000/–0,0254
| • Two flute design is ideal for softer alloyed, non-ferrous material applications that require | CUTTING DIAMETER DC | DECIMAL EQUIVALENT | mm SHANK DIAMETER DCON | LENGTH OF CUT APMX | OVERALL LENGTH LF | ED UNCOATED | P NO. TI-NAMITE-A (AlTiN) | STEELS DCON =h6 |
| slotting or involve heavy chip loads. | 0,1 | 0.0039 | 3,0 | 0,3 | 38,0 | 05018 | 05005 | STAINLESS STEELS |
| • Proprietary coating | 0,2 | 0.0079 | 3,0 | 0,6 | 38,0 | 05020 | 05007 | |
| allows for superior chip flow drivin industr | 0,3 | 0.0118 | 3,0 | 0,9 | 38,0 | 05022 | 05009 | CAST IRON |
| , g y leading productivity | 0,4 | 0.0157 | 3,0 | 1,2 | 38,0 | 05024 | 05011 | HIGH TEMP ALLOYS |
| and value, even at low spindle speeds | 0,5 | 0.0197 | 3,0 | 1,5 | 38,0 | 05025 | 05012 | TITANIUM |
| . • High performance | 0,5 | 0.0197 | 4,0 | 1,5 | 50,0 | 02048 | 03200 | |
| carbide substrate | 0,6 | 0.0236 | 3,0 | 1,8 | 38,0 | 05026 | 05013 | HARDENED STEELS |
| designed specifically for Micro Tool applications. | 0,6 | 0.0236 | 4,0 | 1,8 | 50,0 | 02049 | 03201 | NON-FERROUS |
| • Broad portfolio, offering | 0,7 | 0.0276 | 3,0 | 2,1 | 38,0 | 05027 | 05014 | PLASTICS/COMPOSITES |
| consistent lengths of cut, to ensure application | 0,7 | 0.0276 | 4,0 | 2,1 | 50,0 | 02050 | 03202 | |
| demands are met. | 0,8 | 0.0315 | 3,0 | 2,4 | 38,0 | 05028 | 05015 | |
| • Advanced geometries | 0,8 | 0.0315 | 4,0 | 2,4 | 50,0 | 02051 | 03203 | |
| that extend tool life, reduce chatter, cut cycle | 0,9 | 0.0354 | 3,0 | 2,7 | 38,0 | 05029 | 05016 | |
| times, and improve part ualit | 0,9 | 0.0354 | 4,0 | 2,7 | 50,0 | 02052 | 03204 | |
| qy. • All tools in stock to | 1,0 | 0.0394 | 3,0 | 3,0 | 38,0 | 01949 | 02829 | |
| meet customer order | 1,0 | 0.0394 | 4,0 | 3,0 | 50,0 | 02053 | 03205 | |
| requirements. • All i l | 1,1 | 0.0433 | 3,0 | 3,3 | 38,0 | 01950 | 02940 | |
| mcro toos are manufactured in | 1,1 | 0.0433 | 4,0 | 3,3 | 50,0 | 02054 | 03004 | |
| accordance with the KSPT ISO certified | 1,2 | 0.0472 | 3,0 | 3,6 | 38,0 | 01951 | 02941 | |
| quality procedures. | 1,2 | 0.0472 | 4,0 | 3,6 | 50,0 | 02055 | 03005 | |
| 1,3 | 0.0512 | 3,0 | 3,9 | 38,0 | 01952 | 02942 | ||
| 1,3 | 0.0512 | 4,0 | 3,9 | 50,0 | 02056 | 03006 | ||
| 1,4 | 0.0551 | 3,0 | 4,2 | 38,0 | 01953 | 02943 | ||
| 1,4 | 0.0551 | 4,0 | 4,2 | 50,0 | 02057 | 03007 | ||
| 1,5 | 0.0591 | 3,0 | 4,5 | 38,0 | 01954 | 02944 | ||
| 1,5 | 0.0591 | 4,0 | 4,5 | 50,0 | 02058 | 03008 | ||
| 1,6 | 0.0630 | 3,0 | 4,8 | 38,0 | 01955 | 02945 | ||
| 1,6 | 0.0630 | 4,0 | 4,8 | 50,0 | 02059 | 03009 | ||
| 1,7 | 0.0669 | 3,0 | 5,1 | 38,0 | 01956 | 02946 | ||
| 1,7 | 0.0669 | 4,0 | 5,1 | 50,0 | 02060 | 03010 | ||
| 1,8 | 0.0709 | 3,0 | 5,4 | 38,0 | 01957 | 02947 | ||
| 1,8 | 0.0709 | 4,0 | 5,4 | 50,0 | 02061 | 03011 | ||
| 1,9 | 0.0748 | 3,0 | 5,7 | 38,0 | 01958 | 02948 | ||
| 1,9 | 0.0748 | 4,0 | 5,7 | 50,0 | 02062 | 03012 | ||
| RE = 1/2 Cutti | ng Diameter (D | C) | continue | d on next page |
