Державки Beyond™ Evolution™ Державки Beyond™ Evolution ™ для обработки торцевых канавок
(Державки с прямоугольным хвостовиком, переднее крепление • Метрическая система — продолжение)
поса-
номер номер по дочный крепежный
| заказа | каталогу | размер | CD | D max | H1 | H | B | H2 | L1 | FS | LH | CF | CS | винт Torx | Torx | |||
| левое исполнение | ||||||||||||||||||
| 6179709 | EVSCFL1010K1B10 | 1B | 10 | 20 | 10 | 10 | 10 | 14 | 125 | 9 21 | — | — | 191.916 | T15 | ||||
| 6179922 | EVSCFL1212K1B10 | 1B | 10 | 20 | 12 | 12 | 12 | 16 | 125 | 11 | 21 | — | — | 191.916 | T15 | |||
| 6179923 | EVSCFL1212K1B13 | 1B | 13 | 26 | 12 | 12 | 12 | 16 | 125 | 11 | 24 | — | — | 191.916 | T15 | |||
| 6179930 | EVSCFL1616K1B16 | 1B | 16 | 32 | 16 | 16 | 16 | 21 | 125 | 15 | 27 | — | — | MS1160 | T20 | |||
| 6179934 | EVSCFL2020K1B16 | 1B | 16 | 32 | 20 | 20 | 20 | 25 | 125 | 19 | 27 | — | — | MS1160 | T20 | |||
| 6179710 | EVSCFL1010K1F10 | 1F | 10 | 20 | 10 | 10 | 10 | 14 | 125 | 9 21 | — | — | 191.916 | T15 | ||||
| 6179924 | EVSCFL1212K1F10 | 1F | 10 | 20 | 12 | 12 | 12 | 16 | 125 | 11 | 21 | — | — | 191.916 | T15 | |||
| 6179925 | EVSCFL1212K1F13 | 1F | 13 | 26 | 12 | 12 | 12 | 16 | 125 | 11 | 24 | — | — | 191.916 | T15 | |||
| 6179931 | EVSCFL1616K1F16 | 1F | 16 | 32 | 16 | 16 | 16 | 21 | 125 | 15 | 27 | — | — | MS1160 | T20 | |||
| 6179935 | EVSCFL2020K1F16 | 1F | 16 | 32 | 20 | 20 | 20 | 25 | 125 | 19 | 27 | — | — | MS1160 | T20 | |||
| 6179921 | EVSCFL1010K0210 | 2 | 10 | 20 | 10 | 10 | 10 | 14 | 125 | 9 21 | — | — | 191.916 | T15 | ||||
| 6179926 | EVSCFL1212K0210 | 2 | 10 | 20 | 12 | 12 | 12 | 16 | 125 | 11 | 21 | — | — | 191.916 | T15 | |||
| 6179927 | EVSCFL1212K0216 | 2 | 16 | 32 | 12 | 12 | 12 | 16 | 125 | 11 | 27 | — | — | 191.916 | T15 | |||
| 6179932 | EVSCFL1616K0216 | 2 | 16 | 32 | 16 | 16 | 16 | 21 | 125 | 15 | 27 | — | — | MS1160 | T20 | |||
| 6179936 | EVSCFL2020K0216 | 2 | 16 | 32 | 20 | 20 | 20 | 25 | 125 | 19 | 27 | — | — | MS1160 | T20 | |||
| 6179928 | EVSCFL1212K0310C | 3 | 10 | 20 | 12 | 12 | 12 | 17 | 125 | 11 | 22 | M8X1 | M8X1 | 191.916 | T15 | |||
| 6179929 | EVSCFL1212K0316C | 3 | 16 | 32 | 12 | 12 | 12 | 17 | 125 | 11 | 28 | M8X1 | M8X1 | 191.916 | T15 | |||
| 6179933 | EVSCFL1616K0316C | 3 | 16 | 32 | 16 | 16 | 16 | 21 | 125 | 15 | 28 | M8X1 | M8X1 | MS1160 | T20 | |||
| 6179937 | EVSCFL2020K0316C | 3 | 16 | 32 | 20 | 20 | 20 | 25 | 125 | 19 | 28 | M8X1 | M8X1 | MS1160 | T20 | |||
| ПРИМЕЧАНИЕ. Подвод СОЖ через посадочное гнездо возможен для гнезд размером 3 и выше. | ||||||||||||||||||
| установочный винт | установочный винт | момент затяжки | ключ | ключ | ||||||||||||||
| торцевая | ||||||||||||||||||
| номер по каталогу | номер заказа | Нм | дюйм-фунт | резьба | головка | номер по каталогу | номер заказа | |||||||||||
| MS1160 | 1099645 | 7 | 62 | M5 | T20 | KT20 | 1022703 | |||||||||||
| 9 | 80 | M6 | T25 | |||||||||||||||
| MS1162 | 1127019 | KT25 | 1022725 | |||||||||||||||
| MS1163 | 1124104 | 18 | 159 | M8 | T30 | KT30L | 1099676 | |||||||||||
| MS1273 | 1020977 | 4 | 35.4 | M4 | T15 | KT15 | 1022701 | |||||||||||
| MS1490 | 2263299 | 17 | 151 | M8 | T45 | KT45 | 1018227 | |||||||||||
| MS1595 | 1094300 | 12 | 106 | M6 | T30 | KT30 | 1099676 | |||||||||||
| 12 | 106 | M6 | T30 | |||||||||||||||
| MS1970 | 1106668 | KT30 | 1099676 | |||||||||||||||
| MS2002 | 1621087 | 9 | 80 | M6 | T25 | KT25 | 1022725 | |||||||||||
| MS2091 | 1931147 | 9 | 80 | M5 | 25IP | K25IP | 2050113 |
H=H1
Левое исполнение Левое исполнение
Правое исполнение Правое исполнение
Державки с прямоугольным хвостовиком для торцевых наружных канавок • Метрическая система
поса-
| номер | дочный номер по | D | D | W | крепежный | ||||||||||
| заказа | размер каталогу | CD | max | min | min | B | H2 | L1 | FS | LH | CF | CS винт Torx | Torx | ||
| правое исполнение | |||||||||||||||
| EVSBR2020K0312035040C | 3 | 12 | 40 | 35 | 20 | 20 | 29 | 125 | 19 | 33 | 1/16 - 27 NPTF 1/16 - 27 NPTF | T30 | |||
| 6080031 | MS1595 | ||||||||||||||
| 6116561 | EVSBR2020K0312040050C | 3 | 12 | 50 | 40 | 20 | 20 | 29 | 125 | 19 | 33 | 1/16 - 27 NPTF 1/16 - 27 NPTF | MS1595 | T20 | |
| 6116563 | EVSBR2020K0312050060C | 3 | 12 | 60 | 50 | 20 | 20 | 29 | 125 | 19 | 33 | 1/16 - 27 NPTF 1/16 - 27 NPTF | MS1595 | T30 | |
| 6116567 | EVSBR2020K0312060075C | 3 | 12 | 75 | 60 | 20 | 20 | 29 | 125 | 19 | 33 | 1/16 - 27 NPTF 1/16 - 27 NPTF | MS1595 | T30 | |
| 6116569 | EVSBR2020K0312075100C | 3 | 12 | 100 | 75 | 20 | 20 | 29 | 125 | 19 | 33 | 1/16 - 27 NPTF 1/16 - 27 NPTF | MS1595 | T30 | |
| 6080067 | EVSBR2525M0312100180C | 3 | 12 | 180 100 | 25 | 25 | 34 | 150 | 24 | 33 | 1/8 - 27 NPTF | 1/8 - 27 NPTF | MS1970 | T30 | |
| 6080069 | EVSBR2525M0312180250C | 3 | 12 | 250 180 | 25 | 25 | 34 | 150 | 24 | 33 | 1/8 - 27 NPTF | 1/8 - 27 NPTF | MS1970 | T30 | |
| EVSBR2525M0320060075C | 3 | 20 | 75 | 60 | 25 | 25 | 34 | 150 | 24 | 41 | 1/8 - 27 NPTF | 1/8 - 27 NPTF | T30 | ||
| 6080053 | MS1970 | ||||||||||||||
| 6080055 | EVSBR2525M0320075100C | 3 | 20 | 100 | 75 | 25 | 25 | 34 | 150 | 24 | 41 | 1/8 - 27 NPTF | 1/8 - 27 NPTF | MS1970 | T30 |
| 6080057 | EVSBR2525M0320100180C | 3 | 20 | 180 100 | 25 | 25 | 34 | 150 | 24 | 41 | 1/8 - 27 NPTF | 1/8 - 27 NPTF | MS1970 | T30 | |
| 6080060 | EVSBR2525M0320180250C | 3 | 20 | 250 180 | 25 | 25 | 35 | 150 | 24 | 41 | 1/8 - 27 NPTF | 1/8 - 27 NPTF | MS1970 | T30 | |
| 6080033 | EVSBR2020K0416040050C | 4 | 16 | 50 | 40 | 20 | 20 | 29 | 125 | 18 | 37 | 1/16 - 27 NPTF 1/16 - 27 NPTF | MS1595 | T30 | |
| 6080040 | EVSBR2020K0416050060C | 4 | 16 | 60 | 50 | 20 | 20 | 29 | 125 | 18 | 37 | 1/16 - 27 NPTF 1/16 - 27 NPTF | MS1595 | T30 | |
| 6116571 | EVSBR2020K0416060075C | 4 | 16 | 75 | 60 | 20 | 20 | 29 | 125 | 18 | 37 | 1/16 - 27 NPTF 1/16 - 27 NPTF | MS1595 | T30 | |
| 6116573 | EVSBR2020K0416075100C | 4 | 16 | 100 | 75 | 20 | 20 | 29 | 125 | 18 | 37 | 1/16 - 27 NPTF 1/16 - 27 NPTF | MS1595 | T30 | |
| 6116587 | EVSBR2525M0416100180C | 4 | 16 | 180 100 | 25 | 25 | 34 | 150 | 23 | 37 | 1/8 - 27 NPTF | 1/8 - 27 NPTF | MS1970 | T30 | |
| 6116589 | EVSBR2525M0416180250C | 4 | 16 | 250 180 | 25 | 25 | 34 | 150 | 23 | 37 | 1/8 - 27 NPTF | 1/8 - 27 NPTF | MS1970 | T30 | |
| 6116575 | EVSBR2525M0426060075C | 4 | 26 | 75 | 60 | 25 | 25 | 34 | 150 | 23 | 47 | 1/8 - 27 NPTF | 1/8 - 27 NPTF | MS1970 | T30 |
| 6116577 | EVSBR2525M0426075100C | 4 | 26 | 100 | 75 | 25 | 25 | 34 | 150 | 23 | 47 | 1/8 - 27 NPTF | 1/8 - 27 NPTF | MS1970 | T30 |
| 6116579 | EVSBR2525M0426100180C | 4 | 26 | 180 100 | 25 | 25 | 34 | 150 | 23 | 47 | 1/8 - 27 NPTF | 1/8 - 27 NPTF | MS1970 | T30 | |
| 6116581 | EVSBR2525M0426180250C | 4 | 26 | 250 180 | 25 | 25 | 35 | 150 | 23 | 47 | 1/8 - 27 NPTF | 1/8 - 27 NPTF | MS1970 | T30 | |
| 6080035 | EVSBR2525M0516050060C | 5 | 16 | 60 | 50 | 25 | 25 | 34 | 150 | 23 | 37 | 1/8 - 27 NPTF | 1/8 - 27 NPTF | MS1970 | T30 |
| 6124200 | EVSBR2525M0516060075C | 5 | 16 | 60 | 60 | 25 | 25 | 34 | 150 | 23 | 37 | 1/8 - 27 NPTF | 1/8 - 27 NPTF | MS1970 | T30 |
(продолжение)
| номер | номер по | поса- дочный | D | D | W | крепежный | |||||||||
| заказа | каталогу | размер | CD | max | min | min | B | H2 | L1 | FS | LH | CF | CS | винт Torx | Torx |
| правое ис | полнение | ||||||||||||||
| 6080031 | EVSBR2020K0312035040C | 3 | 12 | 40 | 35 | 20 | 20 | 29 | 125 | 19 | 33 | 1/16 - 27 NPTF | 1/16 - 27 NPTF | MS1595 | T30 |
| 6116561 | EVSBR2020K0312040050C | 3 | 12 | 50 | 40 | 20 | 20 | 29 | 125 | 19 | 33 | 1/16 - 27 NPTF | 1/16 - 27 NPTF | MS1595 | T20 |
| 6116563 | EVSBR2020K0312050060C | 3 | 12 | 60 | 50 | 20 | 20 | 29 | 125 | 19 | 33 | 1/16 - 27 NPTF | 1/16 - 27 NPTF | MS1595 | T30 |
| 6116567 | EVSBR2020K0312060075C | 3 | 12 | 75 | 60 | 20 | 20 | 29 | 125 | 19 | 33 | 1/16 - 27 NPTF | 1/16 - 27 NPTF | MS1595 | T30 |
| 6116569 | EVSBR2020K0312075100C | 3 | 12 | 100 | 75 | 20 | 20 | 29 | 125 | 19 | 33 | 1/16 - 27 NPTF | 1/16 - 27 NPTF | MS1595 | T30 |
| 6080067 | EVSBR2525M0312100180C | 3 | 12 | 180 | 100 | 25 | 25 | 34 | 150 | 24 | 33 | 1/8 - 27 NPTF | 1/8 - 27 NPTF | MS1970 | T30 |
| 6080069 | EVSBR2525M0312180250C | 3 | 12 | 250 | 180 | 25 | 25 | 34 | 150 | 24 | 33 | 1/8 - 27 NPTF | 1/8 - 27 NPTF | MS1970 | T30 |
| 6080053 | EVSBR2525M0320060075C | 3 | 20 | 75 | 60 | 25 | 25 | 34 | 150 | 24 | 41 | 1/8 - 27 NPTF | 1/8 - 27 NPTF | MS1970 | T30 |
| 6080055 | EVSBR2525M0320075100C | 3 | 20 | 100 | 75 | 25 | 25 | 34 | 150 | 24 | 41 | 1/8 - 27 NPTF | 1/8 - 27 NPTF | MS1970 | T30 |
| 6080057 | EVSBR2525M0320100180C | 3 | 20 | 180 | 100 | 25 | 25 | 34 | 150 | 24 | 41 | 1/8 - 27 NPTF | 1/8 - 27 NPTF | MS1970 | T30 |
| 6080060 | EVSBR2525M0320180250C | 3 | 20 | 250 | 180 | 25 | 25 | 35 | 150 | 24 | 41 | 1/8 - 27 NPTF | 1/8 - 27 NPTF | MS1970 | T30 |
| 6080033 | EVSBR2020K0416040050C | 4 | 16 | 50 | 40 | 20 | 20 | 29 | 125 | 18 | 37 | 1/16 - 27 NPTF | 1/16 - 27 NPTF | MS1595 | T30 |
| 6080040 | EVSBR2020K0416050060C | 4 | 16 | 60 | 50 | 20 | 20 | 29 | 125 | 18 | 37 | 1/16 - 27 NPTF | 1/16 - 27 NPTF | MS1595 | T30 |
| 6116571 | EVSBR2020K0416060075C | 4 | 16 | 75 | 60 | 20 | 20 | 29 | 125 | 18 | 37 | 1/16 - 27 NPTF | 1/16 - 27 NPTF | MS1595 | T30 |
| 6116573 | EVSBR2020K0416075100C | 4 | 16 | 100 | 75 | 20 | 20 | 29 | 125 | 18 | 37 | 1/16 - 27 NPTF | 1/16 - 27 NPTF | MS1595 | T30 |
| 6116587 | EVSBR2525M0416100180C | 4 | 16 | 180 | 100 | 25 | 25 | 34 | 150 | 23 | 37 | 1/8 - 27 NPTF | 1/8 - 27 NPTF | MS1970 | T30 |
| 6116589 | EVSBR2525M0416180250C | 4 | 16 | 250 | 180 | 25 | 25 | 34 | 150 | 23 | 37 | 1/8 - 27 NPTF | 1/8 - 27 NPTF | MS1970 | T30 |
| 6116575 | EVSBR2525M0426060075C | 4 | 26 | 75 | 60 | 25 | 25 | 34 | 150 | 23 | 47 | 1/8 - 27 NPTF | 1/8 - 27 NPTF | MS1970 | T30 |
| 6116577 | EVSBR2525M0426075100C | 4 | 26 | 100 | 75 | 25 | 25 | 34 | 150 | 23 | 47 | 1/8 - 27 NPTF | 1/8 - 27 NPTF | MS1970 | T30 |
| 6116579 | EVSBR2525M0426100180C | 4 | 26 | 180 | 100 | 25 | 25 | 34 | 150 | 23 | 47 | 1/8 - 27 NPTF | 1/8 - 27 NPTF | MS1970 | T30 |
| 6116581 | EVSBR2525M0426180250C | 4 | 26 | 250 | 180 | 25 | 25 | 35 | 150 | 23 | 47 | 1/8 - 27 NPTF | 1/8 - 27 NPTF | MS1970 | T30 |
| 6080035 | EVSBR2525M0516050060C | 5 | 16 | 60 | 50 | 25 | 25 | 34 | 150 | 23 | 37 | 1/8 - 27 NPTF | 1/8 - 27 NPTF | MS1970 | T30 |
| 6124200 | EVSBR2525M0516060075C | 5 | 16 | 60 | 60 | 25 | 25 | 34 | 150 | 23 | 37 | 1/8 - 27 NPTF | 1/8 - 27 NPTF | MS1970 | T30 |
