| i | ISO | P M K N S H | ? | re | fmin | fmax | ap min | ap max | 1 2 3 1" | x | w | ||||
| TN 16NL320UN | T8030 | +++ | – | – | – | – | – | – | 32,0 | 0,80 | 0,80 | ||||
| TN 16NL280UN | T8030 | +++ | – | – | – | – | – | – | 28,0 | 0,80 | 0,80 | ||||
| TN 16NL240UN | T8030 | +++ | – | – | – | – | – | – | 24,0 | 0,80 | 0,80 | ||||
| 1 | TN 16NL200UN | T8030 | +++ | – | – | – | – | – | – | 20,0 | 0,80 | 0,80 | |||
| TN 16NL180UN | T8030 | +++ | – | – | – | – | – | – | 18,0 | 0,80 | 0,80 | ||||
| ° | TN 16NL160UN | T8030 | +++ | – | – | – | – | – | – | 16,0 | 0,80 | 0,80 | |||
| 15 | TN 16NL140UN | T8030 | +++ | – | – | – | – | – | – | 14,0 | 1,50 | 1,20 | |||
| E | TN 16NL120UN | T8030 | +++ | – | – | – | – | – | – | 12,0 | 1,50 | 1,20 | |||
| TN 16NL110UN | T8030 | +++ | – | – | – | – | – | – | 11,0 | 1,50 | 1,20 | ||||
| TN 16NL100UN | T8030 | +++ | – | – | – | – | – | – | 10,0 | 1,50 | 1,20 | ||||
| TN 16NL080UN | T8030 | +++ | – | – | – | – | – | – | 8,0 | 1,50 | 1,20 | ||||
| TN 22NL070UN | T8030 | +++ | – | – | – | – | – | – | 7,0 | 2,50 | 1,80 | ||||
| TN 22NL060UN | T8030 | +++ | – | – | – | – | – | – | 6,0 | 2,50 | 1,80 | ||||
| TN 16NR200UN-P1 | T8030 | +++ | – | – | – | – | – | – | 20,0 | 0,80 | 0,80 | ||||
| TN 16NR180UN-P1 | T8030 | +++ | – | – | – | – | – | – | 18,0 | 0,80 | 0,80 | ||||
| 15° | TN 16NR160UN-P1 | T8030 | +++ | – | – | – | – | – | – | 16,0 | 0,80 | 0,80 | |||
| E | TN 16NR140UN-P1 | T8030 | +++ | – | – | – | – | – | – | 14,0 | 1,50 | 1,20 | |||
| TN 16NR120UN-P1 | T8030 | +++ | – | – | – | – | – | – | 12,0 | 1,50 | 1,20 | ||||
| TN 16NR080UN-P1 | T8030 | +++ | – | – | – | – | – | – | 8,0 | 1,50 | 1,20 |
| TN | W EXT | I T323 | |||
| 16 | d 9,525 | l 16,5 | s 3,47 | x s | |
| 22 | 12,700 | 22,0 | 4,71 | w | |
| 55° d (l) 60° |
| i | ISO | P M K N | S H | ? | re | fmin | fmax | ap min | ap max | 1 2 3 1" | x | w | ||||
| TN 16ER280W | T8030 | +++ | – | – | – | – | – | – | 28,0 | 0,80 | 0,80 | |||||
| TN 16ER200W | T8030 | +++ | – | – | – | – | – | – | 20,0 | 0,80 | 0,80 | |||||
| TN 16ER190W | T8030 | +++ | – | – | – | – | – | – | 19,0 | 0,80 | 0,80 | |||||
| 1 | TN 16ER180W | T8030 | +++ | – | – | – | – | – | – | 18,0 | 0,80 | 0,80 | ||||
| TN 16ER160W | T8030 | +++ | – | – | – | – | – | – | 16,0 | 0,80 | 0,80 | |||||
| TN 16ER140W | T8030 | +++ | – | – | – | – | – | – | 14,0 | 1,50 | 1,20 | |||||
| 10° | TN 16ER120W | T8030 | +++ | – | – | – | – | – | – | 12,0 | 1,50 | 1,20 | ||||
| TN 16ER110W | T8030 | +++ | – | – | – | – | – | – | 11,0 | 1,50 | 1,20 | |||||
| E | TN 16ER100W | T8030 | +++ | – | – | – | – | – | – | 10,0 | 1,50 | 1,20 | ||||
| TN 16ER090W | T8030 | +++ | – | – | – | – | – | – | 9,0 | 1,50 | 1,20 | |||||
| TN 16ER080W | T8030 | +++ | – | – | – | – | – | – | 8,0 | 1,50 | 1,20 | |||||
| TN 22ER070W | T8030 | +++ | – | – | – | – | – | – | 7,0 | 2,50 | 1,80 | |||||
| TN 22ER060W | T8030 | +++ | – | – | – | – | – | – | 6,0 | 2,50 | 1,80 | |||||
| TN 22ER050W | T8030 | +++ | – | – | – | – | – | – | 5,0 | 2,50 | 1,70 | |||||
| TN 16EL280W | T8030 | +++ | – | – | – | – | – | – | 28,0 | 0,80 | 0,80 | |||||
| TN 16EL200W | T8030 | +++ | – | – | – | – | – | – | 20,0 | 0,80 | 0,80 | |||||
| 1 | TN 16EL190W | T8030 | +++ | – | – | – | – | – | – | 19,0 | 0,80 | 0,80 | ||||
| TN 16EL160W | T8030 | +++ | – | – | – | – | – | – | 16,0 | 0,80 | 0,80 | |||||
| 10° | TN 16EL140W | T8030 | +++ | – | – | – | – | – | – | 14,0 | 1,50 | 1,20 | ||||
| TN 16EL120W | T8030 | +++ | – | – | – | – | – | – | 12,0 | 1,50 | 1,20 | |||||
| E | TN 16EL110W | T8030 | +++ | – | – | – | – | – | – | 11,0 | 1,50 | 1,20 | ||||
| TN 16EL100W | T8030 | +++ | – | – | – | – | – | – | 10,0 | 1,50 | 1,20 | |||||
| TN 16EL090W | T8030 | +++ | – | – | – | – | – | – | 9,0 | 1,50 | 1,20 | |||||
| TN 16EL080W | T8030 | +++ | – | – | – | – | – | – | 8,0 | 1,50 | 1,20 | |||||
| TN 22EL070W | T8030 | +++ | – | – | – | – | – | – | 7,0 | 2,50 | 1,80 |
