| Type | Cooling Kühln | Taper | Basic d Basis A | imensi bmess | on(mm ungen | ) | Thread- i | Number of teeth Zähne- | Gr So | ade rte | Coredrill Kernbohrer | |||||
| Typ | ug | length Anschnitt- länge | d1 | P | d2 | d3 | l1 | l2 | l3 | a×a | profile Gewinde- profil | Geometr Ausführun | y anzahl g | KTG402 | YK40F | d |
| 4222M-M81-6H 4222MS-M81-6H | Extern Extern | 3P 2P | M8 | 1 | 8 | 6.7 | 90 | 16 | 35 | 6.2 | 60° | B | 4 | ● ● | ○ ○ | 7.6 |
| 4222M-M81.25-6H 4222MS-M81.25-6H | Extern Extern | 3P 2P | M8 | 1.25 | 8 | 6.4 | 90 | 16 | 35 | 6.2 | 60° | B | 4 | ● ● | ○ ○ | 7.45 |
| 4222M-M101-6H 4222MS-M101-6H | Extern Extern | 3P 2P | M10 | 1 | 10 | 8.7 | 100 | 20 | 39 | 8 | 60° | B | 5 | ● ● | ○ ○ | 9.6 |
| 4222M-M101.25-6H 4222MS-M101.25-6H | Extern Extern | 3P 2P | M10 | 1.25 | 10 | 8.4 | 100 | 20 | 39 | 8 | 60° | B | 5 | ● ● | ○ ○ | 9.45 |
| 4222M-M101.5-6H | Extern | 3P | ● | ○ | ||||||||||||
| 4222MS-M101.5-6H 4222MC-M101.5-6H | Extern Intern | 2P 3P | M10 | 1.5 | 10 | 8.1 | 100 | 20 | 39 | 8 | 60° | B | 5 | ● ● | ○ ○ | 9.35 |
| 4222MCS-M101.5-6H | Intern | 2P | ● | ○ | ||||||||||||
| 4222M-M121.25-6H 4222MS-M121.25-6H | Extern Extern | 3P 2P | M12 | 1.25 | 9 | 110 | 24 | 7 | 60° | C | 5 | ● ● | ○ ○ | 11.45 | ||
| 4222M-M121.5-6H 4222MS-M121.5-6H | Extern Extern | 3P 2P | M12 | 1.5 | 9 | 110 | 24 | 7 | 60° | C | 5 | ● ● | ○ ○ | 11.35 | ||
| 4222M-M121.75-6H | Extern | 3P | ● | ○ | ||||||||||||
| 4222MS-M121.75-6H 4222MC-M121.75-6H | Extern Intern | 2P 3P | M12 | 1.75 | 9 | 110 | 24 | 7 | 60° | C | 5 | ● ● | ○ ○ | 11.25 | ||
| 4222MCS-M121.75-6H | Intern | 2P | ● | ○ | ||||||||||||
| 4222M-M141.5-6H 4222MS-M141.5-6H | Extern Extern | 3P 2P | M14 | 1.5 | 11 | 110 | 26 | 9 | 60° | C | 6 | ● ● | ○ ○ | 13.35 | ||
| 4222M-M142-6H 4222MS-M142-6H | Extern Extern | 3P 2P | M14 | 2 | 11 | 110 | 26 | 9 | 60° | C | 6 | ● ● | ○ ○ | 13.1 | ||
| 4222M-M161.5-6H 4222MS-M161.5-6H | Extern Extern | 3P 2P | M16 | 1.5 | 12 | 110 | 27 | 9 | 60° | C | 6 | ● ● | ○ ○ | 15.35 | ||
| 4222M-M162-6H | Extern | 3P | ○ | ○ | ||||||||||||
| 4222MS-M162-6H | Extern | 2P | M16 | 2 | 12 | 110 | 27 | 9 | 60° | C | 6 | ● | ○ | 11 | ||
| 4222MC-M162-6H 4222MCS-M162-6H | Intern Intern | 3P 2P | ● ● | ○ ○ | 5. |
= Very suitable · Sehr empfohlen
Material Overview · Material Übersicht = Suitable · Empfohlen
| Work | piece mate | rial ∙ Werk | stückstoff | ||||||||
| Grade Sorte | Mild steel HB≤180 Baustahl | Carbon steel Alloy Steel Kohlenstoff-, Legierter Stahl | Hardene ~40HRC | d steel · ~50HRC Gehä | ~60HRC rteter Stahl | Stainless steel Rostfreier Stahl | Cast iron Gusseisen | Nodular cast iron GGG Kugelgra- phitguss | Aluminum alloy Aluleg. | Copper alloy Kupferleg. | Heat resist. alloy Warmfeste Leg. |
| KTG402 | | | |||||||||
| YK40F | | | | ||||||||
| Code key ISO Kenn | C 155 zeichen | Cutting data Schnittdaten | C171 | Technical Inf Technische Inf | ormation C1 ormation. | 72-173 | Non-standard Bestellformul | tailor made ar für Sonder | C174 werkzeuge | C |
