Каталог ZCC-CT сверла монолитные - страница 138
Навигация
Каталог ZCC-CT сверла со сменными пластинами
Общий каталог ZCC-CT 2019
Каталог ZCC-CT расточные системы
Каталог ZCC-CT фрезы монолитные
Каталог ZCC-CT фрезы со сменными пластинами
Каталог ZCC-CT оснастка
| Type Typ | Cooling Kühlung | Taper | Basic Basi | dimen s Abme | sion(m ssung | m) en | Thread- i | Number of teeth Zähne- | Grade Sorte | Coredrill Kernbohrer | |||||
| length Anschnitt- länge | d1 | P | d2 | d3 | l1 | l2 | l3 | a×a | profile Gewinde- profil | Geometry Ausführung | anzahl | YK40F | d | ||
| 4222A-M81-6H 4222AS-M81-6H | Extern Extern | 3P 1.5P | M8 | 1 | 8 | 6.7 | 90 | 16 | 35 | 6.2 | 60° | B | 4 | ● ● | 7.6 |
| 4222A-M81.25-6H 4222AS-M81.25-6H | Extern Extern | 3P 1.5P | M8 | 1.25 | 8 | 6.4 | 90 | 16 | 35 | 6.2 | 60° | B | 4 | ○ ○ | 7.45 |
| 4222A-M101-6H 4222AS-M101-6H | Extern Extern | 3P 1.5P | M10 | 1 | 10 | 8.7 | 100 | 20 | 39 | 8 | 60° | B | 5 | ● ● | 9.6 |
| 4222A-M101.25-6H 4222AS-M101.25-6H | Extern Extern | 3P 1.5P | M10 | 1.25 | 10 | 8.4 | 100 | 20 | 39 | 8 | 60° | B | 5 | ● ● | 9.45 |
| 4222A-M101.5-6H | Extern | 3P | ○ | ||||||||||||
| 4222AS-M101.5-6H 4222AC-M101.5-6H | Extern Intern | 1.5P 3P | M10 | 1.5 | 10 | 8.1 | 100 | 20 | 39 | 8 | 60° | B | 5 | ○ ○ | 9.35 |
| 4222ACS-M101.5-6H | Intern | 1.5P | ○ | ||||||||||||
| 4222A-M121.25-6H 4222AS-M121.25-6H | Extern Extern | 3P 1.5P | M12 | 1.25 | 9 | 110 | 24 | 7 | 60° | C | 5 | ● ● | 11.45 | ||
| 4222A-M121.5-6H 4222AS-M121.5-6H | Extern Extern | 3P 1.5P | M12 | 1.5 | 9 | 110 | 24 | 7 | 60° | C | 5 | ● ● | 11.35 | ||
| 4222A-M121.75-6H | Extern | 3P | ○ | ||||||||||||
| 4222AS-M121.75-6H 4222AC-M121.75-6H | Extern Intern | 1.5P 3P | M12 | 1.75 | 9 | 110 | 24 | 7 | 60° | C | 5 | ○ ○ | 11.25 | ||
| 4222ACS-M121.75-6H | Intern | 1.5P | ○ | ||||||||||||
| 4222A-M141.5-6H 4222AS-M141.5-6H | Extern Extern | 3P 1.5P | M14 | 1.5 | 11 | 110 | 26 | 9 | 60° | C | 6 | ● ● | 13.35 | ||
| 4222A-M142-6H 4222AS-M142-6H | Extern Extern | 3P 1.5P | M14 | 2 | 11 | 110 | 26 | 9 | 60° | C | 6 | ● ● | 13.1 | ||
| 4222A-M161.5-6H 4222AS-M161.5-6H | Extern Extern | 3P 1.5P | M16 | 1.5 | 12 | 110 | 27 | 9 | 60° | C | 6 | ● ● | 15.35 | ||
| 4222A-M162-6H | Extern | 3P | ○ | ||||||||||||
| 4222AS-M162-6H | Extern | 1.5P | ° | ○ | |||||||||||
| 4222AC-M162-6H 4222ACS-M162-6H | Intern Intern | 3P 1.5P | M16 | 2 | 12 | 110 | 27 | 9 | 60 | C | 6 | ○ ○ | 15.1 |
= Very suitable · Sehr empfohlen
Material Overview · Material Übersicht = Suitable · Empfohlen
| Work | piece mate | rial ∙ Werks | tückstoff | ||||||||
| Grade Sorte | Mild steel HB≤180 Baustahl | Carbon steel Alloy Steel Kohlenstoff-, Legierter Stahl | Hardene ~40HRC | d steel · ~50HRC Gehä | ~60HRC rteter Stahl | Stainless steel Rostfreier Stahl | Cast iron Gusseisen | Nodular cast iron GGG Kugelgra- phitguss | Aluminum alloy Aluleg. | Copper alloy Kupferleg. | Heat resist. alloy Warmfeste Leg. |
| YK40F | | ||||||||||
| Code key ISO Ken | C 155 nzeichen | Cutting data Schnittdaten | C171 | Technical Inf Technische Inf | ormation C ormation. | 172-173 | Non-standar Bestellformu | d tailor made lar für Sonder | C174 werkzeuge | C |
