Threading · Gewindebearbeitung
Solid carbide taps and cutter · Vollhartmetall-Gewindebohrer, -fräser
4122A Thread forming tap for aluminum alloy machining
Gewindeformer zur Bearbeitung von Aluminiumlegierungen
4222A
A
4122A
B
a
4222A
C
a
ISO 2
(6H)
Basic dimension(mm) Grade Coredrill
Number
Type Basis Abmessungen of teeth
Sorte Kernbohrer
Cooling
Typ Kühlung Taper Thread- Zähne-
length profile Geometry
Anschnitt- d1 P d2 d3 l1 l2 l3 a×a Gewinde- Ausführung
anzahl YK40F d
länge profil
4122A-M1*0.25-6H Extern 3P M1 0.25 3 40 5 60° A 3 ● 0.9
4122AS-M1*0.25-6H Extern 1.5P M1 0.25 3 40 5 60° A 3 ● 0.9
4122A-M1.2*0.25-6H Extern 3P M1.2 0.25 3 40 5 60° A 3 ● 1.1
4122AS-M1.2*0.25-6H Extern 1.5P M1.2 0.25 3 40 5 60° A 3 ● 1.1
4122A-M1.6*0.35-6H Extern 3P M1.6 0.35 3 1.1 40 5 11 60° A 3 ● 1.47
4122AS-M1.6*0.35-6H Extern 1.5P M1.6 0.35 3 1.1 40 5 11 60° A 3 ● 1.47
4122A-M2*0.4-6H Extern 3P M2 0.4 3 1.5 45 6 12 60° A 3 ● 1.85
4122AS-M2*0.4-6H Extern 1.5P M2 0.4 3 1.5 45 6 12 60° A 3 ● 1.85
C
4122A-M2.5*0.45-6H Extern 3P M2.5 0.45 3 1.9 50 6 14 60° A 3 ● 2.33
4122AS-M2.5*0.45-6H Extern 1.5P M2.5 0.45 3 1.9 50 6 14 60° A 3 ● 2.33
4222A-M3*0.5-6H Extern 3P ○
M3 0.5 3.5 2.3 56 6 18 2.7 60° B 4 2.8
4222AS-M3*0.5-6H Extern 1.5P ○
4222A-M4*0.5-6H Extern 3P ●
M4 0.5 4.5 3.1 63 8 21 3.4 60° B 4 3.8
4222AS-M4*0.5-6H Extern 1.5P ●
4222A-M4*0.7-6H Extern 3P ○
M4 0.7 4.5 3.1 63 8 21 3.4 60° B 4 3.7
4222AS-M4*0.7-6H Extern 1.5P ○
4222A-M5*0.5-6H Extern 3P ●
M5 0.5 6 4.3 70 10 25 4.9 60° B 4 4.8
Vollhartmetallbohrer
●
Solid carbide drills
4222AS-M5*0.5-6H Extern 1.5P
4222A-M5*0.8-6H Extern 3P ○
M5 0.8 6 4 70 10 25 4.9 60° B 4 4.65
4222AS-M5*0.8-6H Extern 1.5P ○
4222A-M6*0.75-6H Extern 3P ●
M6 0.75 6 5 80 12 30 4.9 60° B 4 5.7
4222AS-M6*0.75-6H Extern 1.5P ●
4222A-M6*1-6H Extern 3P ○
M6 1 6 4.7 80 12 30 4.9 60° B 4 5.6
4222AS-M6*1-6H Extern 1.5P ○
4222A-M7*1-6H Extern 3P ●
M7 1 7 5.7 80 14 30 5.5 60° B 4 6.6
4222AS-M7*1-6H Extern 1.5P ●
● Ex Stock / ab Lager ○ On demand / auf Anfrage
