GM-2ES series for general machining · GM-2ES Serie für allgemeine Bearbeitung

2-flute micro en 2- Schneiden Mi	l d mills with rco Eckfräs	l straight sha er mit langer	l nk Schneide
		D	1mm≤D	d	L D H 10°
Coat TiAI 35 o	ed N D	0~-0.015
Type		Dimensio Abmessu	n(mm) ngen		Teeth Grade Zähne Sorte
Typ	D	d	H	L	Z KMG303
GM-2ES-D0.3	0.3	4.0	0.6	50	2 ●
GM-2ES-D0.4	0.4	4.0	0.8	50	2 ●
GM-2ES-D0.5	0.5	4.0	1.0	50	2 ●
GM-2ES-D0.6	0.6	4.0	1.2	50	2 ●
GM-2ES-D0.7	0.7	4.0	1.4	50	2 ●
GM-2ES-D0.8	0.8	4.0	1.6	50	2 ●
GM-2ES-D0.9	0.9	4.0	1.8	50	2 ●
GM-2ES-D1.0	1.0	4.0	2.0	50	2 ●
GM-2ES-D1.1	1.1	4.0	2.0	50	2 ●
GM-2ES-D1.2	1.2	4.0	2.5	50	2 ●
GM-2ES-D1.3	1.3	4.0	2.5	50	2 ●
GM-2ES-D1.4	1.4	4.0	3.0	50	2 ●
GM-2ES-D1.5	1.5	4.0	3.0	50	2 ●
GM-2ES-D1.6	1.6	4.0	3.5	50	2 ●
GM-2ES-D1.7	1.7	4.0	3.5	50	2 ●
GM-2ES-D1.8	1.8	4.0	4.0	50	2 ●
GM-2ES-D1.9	1.9	4.0	4.0	50	2 ●
GM-2ES-D2.0	2.0	4.0	4.0	50	2 ●
GM-2ES-D2.1	2.1	4.0	4.0	50	2 ●
GM-2ES-D2.2	2.2	4.0	4.5	50	2 ●
GM-2ES-D2.3	2.3	4.0	4.5	50	2 ●
GM-2ES-D2.4	2.4	4.0	5.0	50	2 ●
GM-2ES-D2.5	2.5	4.0	5.0	50	2 ●
GM-2ES-D2.6	2.6	4.0	5.0	50	2 ●
GM-2ES-D2.7	2.7	4.0	5.5	50	2 ●
GM-2ES-D2.8	2.8	4.0	5.5	50	2 ●
GM-2ES-D2.9	2.9	4.0	6.0	50	2 ●
GM-2ES-D3.0	3.0	4.0	6.0	50	2 ●
Material Overvie	w · Material	Übersicht			= Very suitable · = Suitable · Sehr empfohlen Empfohlen

Carbon steel Kohlenstoff Stahl	Alloy steel Legierter Stahl	Quench tempere ~40HRC Vergütet	ed and d steel · ~50HRC er Stahl	Hardene ~55HRC Gehärtet	Workpiece d steel · ~68HRC Werkstü er Stahl	material Stainless steel · ckstoff Rostfreier Stahl	Cast iron, Nodular cast iron Grauguss GGG	Copper alloy Kupfer Leg	Aluminum alloy Alu Leg	Titanium alloy Titan Leg	Heat resist alloy warmfeste Leg
							
