| BSW | TCTR (tolerance) | Ø (mm) | Hole Ø (mm) | Code | THCHT (chamfer) | LF ( mm ) | THL ( mm ) | LU ( mm ) | LS ( mm ) | DCON ( mm ) | K ( mm ) | LK ( mm ) | NOF | Type | Stock | Intro |
| JIS | ||||||||||||||||
| 1/2W12 | P3 | 10.6 | 10.7 | SPRW08SL15 | 2.5P | 150 | 26 | - | 60 | 10.5 | 8 | 11 | 3 | 008 | f | |
| P3 | 10.6 | 10.7 | SPRW08SL20 | 2.5P | 200 | 26 | - | 60 | 10.5 | 8 | 11 | 3 | 008 | f | SP | |
| 5/8W11 | P3 | 13.5 | 13.68 | SPRW10UL15 | 2.5P | 150 | 26 | - | 60 | 12.5 | 10 | 13 | 3 | 008 | f | |
| P3 | 13.5 | 13.68 | SPRW10UL20 | 2.5P | 200 | 26 | - | 60 | 12.5 | 10 | 13 | 3 | 008 | f | ||
| 3/4W10 | P3 | 16.5 | 16.63 | SPRW12VL15 | 2.5P | 150 | 33 | - | 70 | 15 | 12 | 15 | 4 | 008 | f | |
| P3 | 16.5 | 16.63 | SPRW12VL20 | 2.5P | 200 | 33 | - | 70 | 15 | 12 | 15 | 4 | 008 | f | SL | |
| 7/8W9 | P3 | 19.5 | 19.53 | SPRW14WL15 | 2.5P | 150 | 33 | - | 70 | 17 | 13 | 16 | 4 | 008 | f | |
| P3 | 19.5 | 19.53 | SPRW14WL20 | 2.5P | 200 | 33 | - | 70 | 17 | 13 | 16 | 4 | 008 | f | ||
| 1 W8 | P3 | 22.2 | 22.34 | SPRW16XL15 | 2.5P | 150 | 39 | - | 80 | 19 | 15 | 18 | 4 | 008 | f | PO |
| P3 | 22.2 | 22.34 | SPRW16XL20 | 2.5P | 200 | 39 | - | 80 | 19 | 15 | 18 | 4 | 008 | f |
