Long Taps Intro M TCTR Ø Hole Ø(tolerance)(mm)(mm)CodeTHCHT(chamfer)LF(mm)THL(mm) LU(mm) LS DCON K(mm)(mm)(mm)LK(mm)NOFTypeStock JIS P2 8.5 8.6 SPQ010OL10 2.5P 100 23 - 50 7 5.5 8 3 008 f SP P2 8.5 8.6 SPQ010OL12 2.5P 120 23 - 50 7 5.5 8 3 008 f P2 8.5 8.6 SPQ010OL15 2.5P 150 23 - 50 7 5.5 8 3 008 h M10X1.5 P2 8.5 8.6 SPQ010OL20 2.5P 200 23 - 50 7 5.5 8 3 008 h P3(P2+20) 8.5 8.6 SPR010OL10 2.5P 100 23 - 50 7 5.5 8 3 008 f SL P3(P2+20) 8.5 8.6 SPR010OL15 2.5P 150 23 - 50 7 5.5 8 3 008 f P2 10.3 10.36 SPQ012PL10 2.5P 100 26 - 50 8.5 6.5 9 3 008 f P2 10.3 10.36 SPQ012PL12 2.5P 120 26 - 50 8.5 6.5 9 3 008 f PO M12X1.75 P2 10.3 10.36 SPQ012PL15 2.5P 150 26 - 50 8.5 6.5 9 3 008 h P2 10.3 10.36 SPQ012PL20 2.5P 200 26 - 50 8.5 6.5 9 3 008 h P3(P2+20) 10.3 10.36 SPR012PL15 2.5P 150 26 - 50 8.5 6.5 9 3 008 f P2 12 12.12 SPQ014QL12 2.5P 120 26 - 60 10.5 8 11 3 008 f ST M14X2 P2 12 12.12 SPQ014QL15 2.5P 150 26 - 60 10.5 8 11 3 008 h P2 12 12.12 SPQ014QL20 2.5P 200 26 - 60 10.5 8 11 3 008 f P2 14 14.12 SPQ016QL15 2.5P 150 26 - 60 12.5 10 13 3 008 h ROLL M16X2 P2 14 14.12 SPQ016QL20 2.5P 200 26 - 60 12.5 10 13 3 008 hP21414.12SPQ016QL252.5P25026-6012.510133008f P3 15.5 15.63 SPR018RL15 2.5P 150 33 - 70 14 11 14 4 008 f M18X2.5 P3 15.5 15.63 SPR018RL20 2.5P 200 33 - 70 14 11 14 4 008 f CARBIDE P3 15.5 15.63 SPR018RL25 2.5P 250 33 - 70 14 11 14 4 008 f P3 17.5 17.63 SPR020RL15 2.5P 150 33 - 70 15 12 15 4 008 f M20X2.5 P3 17.5 17.63 SPR020RL20 2.5P 200 33 - 70 15 12 15 4 008 h P3 17.5 17.63 SPR020RL25 2.5P 250 33 - 70 15 12 15 4 008 f LONG P3 19.5 19.63 SPR022RL15 2.5P 150 33 - 70 17 13 16 4 008 f JIS M22X2.5 P3 19.5 19.63 SPR022RL20 2.5P 200 33 - 70 17 13 16 4 008 f P3 19.5 19.63 SPR022RL25 2.5P 250 33 - 70 17 13 16 4 008 f HAND P3 21 21.13 SPR024SL15 2.5P 150 39 - 80 19 15 18 4 008 f TAPS M24X3 P3 21 21.13 SPR024SL20 2.5P 200 39 - 80 19 15 18 4 008 h P3 21 21.13 SPR024SL25 2.5P 250 39 - 80 19 15 18 4 008 f P3 24 24.13 SPR027SL20 2.5P 200 39 - 80 20 15 18 4 008 f EG (STI) M27X3 P3 24 24.13 SPR027SL25 2.5P 250 39 - 80 20 15 18 4 008 f P4 26.5 26.63 SPS030TL20 2.5P 200 46 - 80 23 17 20 4 008 f M30X3.5 P4 26.5 26.63 SPS030TL25 2.5P 250 46 - 80 23 17 20 4 008 f SPECIAL P4 26.5 26.63 SPS030TL30 2.5P 300 46 - 80 23 17 20 4 008 f THREADS, GAUGES MF TCTR Ø Hole Ø(tolerance)(mm)(mm)CodeTHCHT(chamfer)LF(mm)THL(mm) LU(mm) LS DCON K(mm)(mm)(mm)LK(mm)NOFTypeStock JIS THREAD M6X0.75 P2 5.3 5.33 SPFQ6.0JL10 2.5P 100 15 30 40 6 4.5 7 3 005 f MILLS P2 7 7.09 SPQ8.0ML10 2.5P 100 19 - 50 6.2 5 8 3 008 f M8X1 P2 7 7.09 SPQ8.0ML15 2.5P 150 19 - 50 6.2 5 8 3 008 f P2 7 7.09 SPQ8.0ML12 2.5P 120 19 - 50 6.2 5 8 3 008 f DIES M8X0.75 P2 7.25 7.33 SPQ8.0JL10 2.5P 100 19 - 50 6.2 5 8 3 008 f P2 8.8 8.85 SPQ010NL10 2.5P 100 23 - 50 7 5.5 8 3 008 f P2 8.8 8.85 SPQ010NL12 2.5P 120 23 - 50 7 5.5 8 3 008 f M10X1.25 CENTER P2 8.8 8.85 SPQ010NL15 2.5P 150 23 - 50 7 5.5 8 3 008 f DRILLS P2 8.8 8.85 SPQ010NL20 2.5P 200 23 - 50 7 5.5 8 3 008 f Technical info 442
