| MF | TCTR (tolerance) | Bored Hol Max | e Ø(mm) Min | Code | THCHT (chamfer) | LF ( mm ) | THL ( mm ) | LU ( mm ) | LS ( mm ) | DCON ( mm ) | K ( mm ) | LK ( mm ) | NOF (Lobes) | Type | Stock | Intro |
| JIS | ||||||||||||||||
| G4 | 1.91 | 1.89 | NRSM42.0BP | 4P | 42 | 4.5 | - | 27 | 3 | 2.5 | 5 | 0(4) | 010 | f | ||
| M2X025 | G4 | 1.91 | 1.89 | NRSM42.0BB | 2P | 42 | 4.5 | - | 27 | 3 | 2.5 | 5 | 0(4) | 010 | f | SP |
| . | G5(G4+13) | 1.93 | 1.9 | NRSM52.0BP | 4P | 42 | 4.5 | - | 27 | 3 | 2.5 | 5 | 0(4) | 010 | f | |
| G5(G4+13) | 1.93 | 1.9 | NRSM52.0BB | 2P | 42 | 4.5 | - | 27 | 3 | 2.5 | 5 | 0(4) | 010 | f | ||
| G4 | 2.35 | 2.33 | NRSM42.5DP | 4P | 46 | 6.3 | 14 | 29 | 3 | 2.5 | 5 | 0(4) | 012 | f | ||
| M25X035 | G4 | 2.35 | 2.33 | NRSM42.5DB | 2P | 46 | 6.3 | 14 | 29 | 3 | 2.5 | 5 | 0(4) | 012 | f | SL |
| .. | G5 | 2.37 | 2.36 | NRSM52.5DP | 4P | 46 | 6.3 | 14 | 29 | 3 | 2.5 | 5 | 0(4) | 012 | f | |
| G5 | 2.37 | 2.36 | NRSM52.5DB | 2P | 46 | 6.3 | 14 | 29 | 3 | 2.5 | 5 | 0(4) | 012 | f | ||
| G5 | 2.42 | 2.4 | NRSM52.6DP | 4P | 46 | 6.3 | 14 | 29 | 3 | 2.5 | 5 | 0(4) | 012 | f | PO | |
| M26X035 | G5 | 2.42 | 2.4 | NRSM52.6DB | 2P | 46 | 6.3 | 14 | 29 | 3 | 2.5 | 5 | 0(4) | 012 | f | |
| .. | G6(G5+13) | 2.44 | 2.41 | NRSM62.6DP | 4P | 46 | 6.3 | 14 | 29 | 3 | 2.5 | 5 | 0(4) | 012 | f | |
| G6(G5+13) | 2.44 | 2.41 | NRSM62.6DB | 2P | 46 | 6.3 | 14 | 29 | 3 | 2.5 | 5 | 0(4) | 012 | f | ||
| G5 | 2.86 | 2.79 | NRSM53.0DP | 4P | 46 | 6.5 | 14 | 26 | 4 | 3.2 | 6 | 1(4) | 012 | f | ST | |
| M3X035 | G5 | 2.86 | 2.79 | NRSM53.0DB | 2P | 46 | 6.5 | 14 | 26 | 4 | 3.2 | 6 | 1(4) | 012 | f | |
| . | G6(G5+13) | 2.87 | 2.8 | NRSM63.0DP | 4P | 46 | 6.5 | 14 | 26 | 4 | 3.2 | 6 | 1(4) | 012 | f | |
| G6(G5+13) | 2.87 | 2.8 | NRSM63.0DB | 2P | 46 | 6.5 | 14 | 26 | 4 | 3.2 | 6 | 1(4) | 012 | f | R | |
| G5 | 3.25 | 3.22 | NRSM53.5DP | 4P | 52 | 6.5 | 16 | 29 | 5 | 4 | 7 | 1(4) | 012 | f | OLL | |
| M35X035 | G5 | 3.25 | 3.22 | NRSM53.5DB | 2P | 52 | 6.5 | 16 | 29 | 5 | 4 | 7 | 1(4) | 012 | f | JIS |
| .. | G6(G5+13) | 3.26 | 3.23 | NRSM63.5DP | 4P | 52 | 6.5 | 16 | 29 | 5 | 4 | 7 | 1(4) | 012 | f | |
| G6(G5+13) | 3.26 | 3.23 | NRSM63.5DB | 2P | 52 | 6.5 | 16 | 29 | 5 | 4 | 7 | 1(4) | 012 | f | CARBIDE | |
| G6 | 3.81 | 3.76 | NRSM64.0GP | 4P | 52 | 9 | 17 | 29 | 5 | 4 | 7 | 1(4) | 012 | f | ||
| G6 | 381 | 376 | NRSM640GB | 2P | 52 | 9 | 17 | 29 | 5 | 4 | 7 | 14 | 012 | f | ||
| M4X05 | . | . | . | () | ||||||||||||
| . | G7(G6+13) | 3.82 | 3.77 | NRSM74.0GP | 4P | 52 | 9 | 17 | 29 | 5 | 4 | 7 | 1(4) | 012 | f | |
| G7(G6+13) | 3.82 | 3.77 | NRSM74.0GB | 2P | 52 | 9 | 17 | 29 | 5 | 4 | 7 | 1(4) | 012 | f | LONG | |
| G6 | 4.81 | 4.76 | NRSM65.0GP | 4P | 60 | 9 | 22 | 33 | 5.5 | 4.5 | 7 | 1(4) | 012 | f | ||
| MX | G6 | 4.81 | 4.76 | NRSM65.0GB | 2P | 60 | 9 | 22 | 33 | 5.5 | 4.5 | 7 | 1(4) | 012 | f | |
| 50.5 | G7(G6+13) | 4.82 | 4.77 | NRSM75.0GP | 4P | 60 | 9 | 22 | 33 | 5.5 | 4.5 | 7 | 1(4) | 012 | f | HAND |
| G7(G6+13) | 4.82 | 4.77 | NRSM75.0GB | 2P | 60 | 9 | 22 | 33 | 5.5 | 4.5 | 7 | 1(4) | 012 | f | TAPS | |
| G6 | 5.69 | 5.61 | NRSM66.0JP | 4P | 62 | 15 | 26 | 33 | 6 | 4.5 | 7 | 1(4) | 012 | f | ||
| G6 | 5.69 | 5.61 | NRSM66.0JB | 2P | 62 | 15 | 26 | 33 | 6 | 4.5 | 7 | 1(4) | 012 | f | ||
| M6X0.75 | G7(G6+13) | 5.7 | 5.62 | NRSM76.0JP | 4P | 62 | 15 | 26 | 33 | 6 | 4.5 | 7 | 1(4) | 012 | f | EG (STI) |
| G7(G6+13) | 5.7 | 5.62 | NRSM76.0JB | 2P | 62 | 15 | 26 | 33 | 6 | 4.5 | 7 | 1(4) | 012 | f | ||
| G6 | 5.81 | 5.76 | NRSM66.0GP | 4P | 62 | 9 | 26 | 33 | 6 | 4.5 | 7 | 1(4) | 012 | f | ||
| M6X0.5 | G6 | 5.81 | 5.76 | NRSM66.0GB | 2P | 62 | 9 | 26 | 33 | 6 | 4.5 | 7 | 1(4) | 012 | f | SPECIAL THREADS |
| M7X075 | G7 | 6.7 | 6.62 | NRSM77.0JP | 4P | 70 | 19 | - | 36 | 6.2 | 5 | 8 | 1(4) | 026 | f | , GAUGES |
| . | G7 | 6.7 | 6.62 | NRSM77.0JB | 2P | 70 | 19 | - | 36 | 6.2 | 5 | 8 | 1(4) | 026 | f | |
| M8X1 | G7 | 7.59 | 7.48 | NRSM78.0MP | 4P | 70 | 19 | - | 36 | 6.2 | 5 | 8 | 1(6) | 026 | f | |
| G7 | 7.59 | 7.48 | NRSM78.0MB | 2P | 70 | 19 | - | 36 | 6.2 | 5 | 8 | 1(6) | 026 | f | THREAD | |
| G7 | 7.7 | 7.62 | NRSM78.0JP | 4P | 70 | 19 | - | 36 | 6.2 | 5 | 8 | 1(6) | 026 | f | MILLS | |
| M8X0.75 | G7 | 7.7 | 7.62 | NRSM78.0JB | 2P | 70 | 19 | - | 36 | 6.2 | 5 | 8 | 1(6) | 026 | f | |
| G7 | 9.49 | 9.35 | NRSM7010NP | 4P | 75 | 23 | - | 38 | 7 | 5.5 | 8 | 1(6) | 026 | f | ||
| G7 | 9.49 | 9.35 | NRSM7010NB | 2P | 75 | 23 | - | 38 | 7 | 5.5 | 8 | 1(6) | 026 | f | DIES | |
| M10X1.25 | ||||||||||||||||
| G8(G7+13) | 9.5 | 9.37 | NRSM8010NP | 4P | 75 | 23 | - | 38 | 7 | 5.5 | 8 | 1(6) | 026 | f | ||
| G8(G7+13) | 9.5 | 9.37 | NRSM8010NB | 2P | 75 | 23 | - | 38 | 7 | 5.5 | 8 | 1(6) | 026 | f | ||
| G7 | 9.59 | 9.48 | NRSM7010MP | 4P | 75 | 23 | - | 38 | 7 | 5.5 | 8 | 1(6) | 026 | f | CENTER | |
| M10X1 | G7 | 9.59 | 9.48 | NRSM7010MB | 2P | 75 | 23 | - | 38 | 7 | 5.5 | 8 | 1(6) | 026 | f | DRILLS |
