| Intro | MF | TCTR (tolerance) | Bored Hole Max | Ø(mm) Min | Code | THCHT (chamfer) | LF ( mm ) | THL ( mm ) | LU ( mm ) | LS ( mm ) | DCON ( mm ) | K ( mm ) | LK ( mm ) | NOF (Lobes) | Type | Stock |
| JIS | ||||||||||||||||
| G8 | 11.38 | 11.22 | NRSM8012OP | 4P | 82 | 26 | - | 42 | 8.5 | 6.5 | 9 | 1(6) | 026 | f | ||
| SP | M12X15 | G8 | 11.38 | 11.22 | NRSM8012OB | 2P | 82 | 26 | - | 42 | 8.5 | 6.5 | 9 | 1(6) | 026 | f |
| . | G9(G8+13) | 11.39 | 11.23 | NRSM9012OP | 4P | 82 | 26 | - | 42 | 8.5 | 6.5 | 9 | 1(6) | 026 | f | |
| G9(G8+13) | 11.39 | 11.23 | NRSM9012OB | 2P | 82 | 26 | - | 42 | 8.5 | 6.5 | 9 | 1(6) | 026 | f | ||
| G8 | 11.49 | 11.35 | NRSM8012NP | 4P | 82 | 26 | - | 42 | 8.5 | 6.5 | 9 | 1(6) | 026 | f | ||
| SL | G8 | 11.49 | 11.35 | NRSM8012NB | 2P | 82 | 26 | - | 42 | 8.5 | 6.5 | 9 | 1(6) | 026 | f | |
| M12X1.25 | G9 | 11.5 | 11.36 | NRSM9012NP | 4P | 82 | 26 | - | 42 | 8.5 | 6.5 | 9 | 1(6) | 026 | f | |
| G9 | 11.5 | 11.36 | NRSM9012NB | 2P | 82 | 26 | - | 42 | 8.5 | 6.5 | 9 | 1(6) | 026 | f | ||
| PO | M12X1 | G7 | 11.58 | 11.47 | NRSM7012MP | 4P | 82 | 26 | - | 42 | 8.5 | 6.5 | 9 | 1(6) | 026 | f |
| G7 | 11.58 | 11.47 | NRSM7012MB | 2P | 82 | 26 | - | 42 | 8.5 | 6.5 | 9 | 1(6) | 026 | f | ||
| MX | G9 | 13.39 | 13.22 | NRSM9014OP | 4P | 88 | 26 | - | 45 | 10.5 | 8 | 11 | 1(6) | 026 | f | |
| 141.5 | G9 | 13.39 | 13.22 | NRSM9014OB | 2P | 88 | 26 | - | 45 | 10.5 | 8 | 11 | 1(6) | 026 | f | |
| ST | M14X1 | G8 | 13.59 | 13.48 | NRSM8014MP | 4P | 88 | 26 | - | 45 | 10.5 | 8 | 11 | 1(6) | 026 | f |
| G8 | 13.59 | 13.48 | NRSM8014MB | 2P | 88 | 26 | - | 45 | 10.5 | 8 | 11 | 1(6) | 026 | f | ||
| G9 | 15.38 | 15.22 | NRSM9016OP | 4P | 95 | 26 | - | 48 | 12.5 | 10 | 13 | 1(6) | 026 | f | ||
| M16X1.5 | G9 | 15.38 | 15.22 | NRSM9016OB | 2P | 95 | 26 | - | 48 | 12.5 | 10 | 13 | 1(6) | 026 | f | |
| ROLL | G8 | 15.59 | 15.48 | NRSM8016MP | 4P | 95 | 26 | - | 48 | 12.5 | 10 | 13 | 1(6) | 026 | f | |
| JIS | M16X1 | G8 | 15.59 | 15.48 | NRSM8016MB | 2P | 95 | 26 | - | 48 | 12.5 | 10 | 13 | 1(6) | 026 | f |
| M18X1 | G9 | 17.38 | 17.22 | NRSM9018OP | 4P | 100 | 33 | - | 51 | 14 | 11 | 14 | 1(6) | 026 | f | |
| CARBIDE | .5 | G9 | 17.38 | 17.22 | NRSM9018OB | 2P | 100 | 33 | - | 51 | 14 | 11 | 14 | 1(6) | 026 | f |
| G9 | 19.37 | 19.21 | NRSM9020OP | 4P | 105 | 33 | - | 50 | 15 | 12 | 15 | 1(6) | 026 | f | ||
| G9 | 19.37 | 19.21 | NRSM9020OB | 2P | 105 | 33 | - | 50 | 15 | 12 | 15 | 1(6) | 026 | f | ||
| M20X1.5 | G10 | 19.39 | 19.22 | NRSM0020OP | 4P | 105 | 33 | - | 50 | 15 | 12 | 15 | 1(6) | 026 | f | |
| LONG | G10 | 19.39 | 19.22 | NRSM0020OB | 2P | 105 | 33 | - | 50 | 15 | 12 | 15 | 1(6) | 026 | f | |
| UNC | TCTR (tolerance) | Bored Hole Max | Ø(mm) Min | Code | THCHT (chamfer) | LF ( mm ) | THL ( mm ) | LU ( mm ) | LS ( mm ) | DCON ( mm ) | K ( mm ) | LK ( mm ) | NOF (Lobes) | Type | Stock | |
| HAND | JIS | |||||||||||||||
| TAPS | G4 | 2.01 | 1.96 | NRSM4UN2EP | 4P | 42 | 8.1 | - | 27 | 3 | 2.5 | 5 | 0(4) | 010 | f | |
| G4 | 2.01 | 1.96 | NRSM4UN2EB | 2P | 42 | 8.1 | - | 27 | 3 | 2.5 | 5 | 0(4) | 010 | f | ||
| G5(G4+13) | 2.02 | 1.97 | NRSM5UN2EP | 4P | 42 | 8.1 | - | 27 | 3 | 2.5 | 5 | 0(4) | 010 | f | ||
| EG (STI) | G5(G4+13) | 2.02 | 1.97 | NRSM5UN2EB | 2P | 42 | 8.1 | - | 27 | 3 | 2.5 | 5 | 0(4) | 010 | f | |
| No.2-56UNC | G7(G4+39) | 2.04 | 2 | NRSM7UN2EP | 4P | 42 | 8.1 | - | 27 | 3 | 2.5 | 5 | 0(4) | 010 | f | |
| G7(G4+39) | 2.04 | 2 | NRSM7UN2EB | 2P | 42 | 8.1 | - | 27 | 3 | 2.5 | 5 | 0(4) | 010 | f | ||
| SPECIAL | G6(G4+26) | 2.03 | 1.98 | NRSM6UN2EP | 4P | 42 | 8.1 | - | 27 | 3 | 2.5 | 5 | 0(4) | 010 | f | |
| THREADS, GAUGES | G6(G4+26) | 2.03 | 1.98 | NRSM6UN2EB | 2P | 42 | 8.1 | - | 27 | 3 | 2.5 | 5 | 0(4) | 010 | f | |
| G4 | 2.31 | 2.25 | NRSM4UN3FP | 4P | 46 | 8.1 | 14 | 29 | 3 | 2.5 | 5 | 0(4) | 012 | f | ||
| N3-48UNC | G4 | 2.31 | 2.25 | NRSM4UN3FB | 2P | 46 | 8.1 | 14 | 29 | 3 | 2.5 | 5 | 0(4) | 012 | f | |
| THREAD | o. | G5(G4+13) | 2.32 | 2.26 | NRSM5UN3FP | 4P | 46 | 8.1 | 14 | 29 | 3 | 2.5 | 5 | 0(4) | 012 | f |
| MILLS | G5(G4+13) | 2.32 | 2.26 | NRSM5UN3FB | 2P | 46 | 8.1 | 14 | 29 | 3 | 2.5 | 5 | 0(4) | 012 | f | |
| G5 | 2.61 | 2.54 | NRSM5UN4HP | 4P | 46 | 9 | 14 | 26 | 4 | 3.2 | 6 | 0(4) | 012 | f | ||
| G5 | 2.61 | 2.54 | NRSM5UN4HB | 2P | 46 | 9 | 14 | 26 | 4 | 3.2 | 6 | 0(4) | 012 | f | ||
| DIES | G6(G5+13) | 2.62 | 2.55 | NRSM6UN4HP | 4P | 46 | 9 | 14 | 26 | 4 | 3.2 | 6 | 0(4) | 012 | f | |
| No.4-40UNC | G6(G5+13) | 2.62 | 2.55 | NRSM6UN4HB | 2P | 46 | 9 | 14 | 26 | 4 | 3.2 | 6 | 0(4) | 012 | f | |
| G7(G5+26) | 2.63 | 2.57 | NRSM7UN4HP | 4P | 46 | 9 | 14 | 26 | 4 | 3.2 | 6 | 0(4) | 012 | f | ||
| CENTER | G7(G5+26) | 2.63 | 2.57 | NRSM7UN4HB | 2P | 46 | 9 | 14 | 26 | 4 | 3.2 | 6 | 0(4) | 012 | f | |
| DRILLS | No.5-40UNC | G5 | 2.94 | 2.87 | NRSM5UN5HP | 4P | 52 | 11 | 16 | 28 | 5 | 4 | 7 | 1(4) | 012 | f |
