| M | TCTR (tolerance) | Bored Hol Max | e Ø(mm) Min | Code | THCHT (chamfer) | LF ( mm ) | THL ( mm ) | LU ( mm ) | LS ( mm ) | DCON ( mm ) | K ( mm ) | LK ( mm ) | NOF (Lobes) | Type | Stock | Intro |
| JIS | ||||||||||||||||
| G4 | 1.46 | 1.43 | NRSP41.6DP | 4P | 36 | 6.3 | - | 24 | 3 | 2.5 | 5 | 0(4) | 010 | f | ||
| G4 | 1.46 | 1.43 | NRSP41.6DB | 2P | 36 | 6.3 | - | 24 | 3 | 2.5 | 5 | 0(4) | 010 | f | SP | |
| M1.6X0.35 | G5(G4+13) | 1.48 | 1.44 | NRSP51.6DP | 4P | 36 | 6.3 | - | 24 | 3 | 2.5 | 5 | 0(4) | 010 | f | |
| G5(G4+13) | 1.48 | 1.44 | NRSP51.6DB | 2P | 36 | 6.3 | - | 24 | 3 | 2.5 | 5 | 0(4) | 010 | f | ||
| G4 | 1.56 | 1.52 | NRSP41.7DP | 4P | 36 | 6.3 | - | 24 | 3 | 2.5 | 5 | 0(4) | 010 | f | ||
| G4 | 1.56 | 1.52 | NRSP41.7DB | 2P | 36 | 6.3 | - | 24 | 3 | 2.5 | 5 | 0(4) | 010 | f | SL | |
| M17X035 | G5(G4+13) | 1.58 | 1.54 | NRSP51.7DP | 4P | 36 | 6.3 | - | 24 | 3 | 2.5 | 5 | 0(4) | 010 | f | |
| .. | G5(G4+13) | 1.58 | 1.54 | NRSP51.7DB | 2P | 36 | 6.3 | - | 24 | 3 | 2.5 | 5 | 0(4) | 010 | f | |
| G6(G4+26) | 1.59 | 1.55 | NRSP61.7DP | 4P | 36 | 6.3 | - | 24 | 3 | 2.5 | 5 | 0(4) | 010 | f | PO | |
| G6(G4+26) | 1.59 | 1.55 | NRSP61.7DB | 2P | 36 | 6.3 | - | 24 | 3 | 2.5 | 5 | 0(4) | 010 | f | ||
| G4 | 1.66 | 1.62 | NRSP41.8DP | 4P | 42 | 6.3 | - | 27 | 3 | 2.5 | 5 | 0(4) | 010 | f | ||
| G4 | 1.66 | 1.62 | NRSP41.8DB | 2P | 42 | 6.3 | - | 27 | 3 | 2.5 | 5 | 0(4) | 010 | f | ||
| M1.8X0.35 | G5(G4+13) | 1.68 | 1.64 | NRSP51.8DP | 4P | 42 | 6.3 | - | 27 | 3 | 2.5 | 5 | 0(4) | 010 | f | ST |
| G5(G4+13) | 1.68 | 1.64 | NRSP51.8DB | 2P | 42 | 6.3 | - | 27 | 3 | 2.5 | 5 | 0(4) | 010 | f | ||
| G4 | 1.83 | 1.79 | NRSP42.0EP | 4P | 42 | 7.2 | - | 27 | 3 | 2.5 | 5 | 0(4) | 010 | f | ||
| G4 | 1.83 | 1.79 | NRSP42.0EB | 2P | 42 | 7.2 | - | 27 | 3 | 2.5 | 5 | 0(4) | 010 | f | ||
| M2X04 | G5(G4+13) | 1.84 | 1.8 | NRSP52.0EP | 4P | 42 | 7.2 | - | 27 | 3 | 2.5 | 5 | 0(4) | 010 | f | ROLL |
| . | G5(G4+13) | 1.84 | 1.8 | NRSP52.0EB | 2P | 42 | 7.2 | - | 27 | 3 | 2.5 | 5 | 0(4) | 010 | f | JIS |
| G6(G4+26) | 1.86 | 1.81 | NRSP62.0EP | 4P | 42 | 7.2 | - | 27 | 3 | 2.5 | 5 | 0(4) | 010 | f | ||
| G6(G4+26) | 1.86 | 1.81 | NRSP62.0EB | 2P | 42 | 7.2 | - | 27 | 3 | 2.5 | 5 | 0(4) | 010 | f | CARBIDE | |
| G4 | 2.13 | 2.09 | NRSP42.3EP | 4P | 42 | 7.2 | - | 27 | 3 | 2.5 | 5 | 0(4) | 010 | f | ||
| G4 | 2.13 | 2.09 | NRSP42.3EB | 2P | 42 | 7.2 | - | 27 | 3 | 2.5 | 5 | 0(4) | 010 | f | ||
| M23X04 | G5(G4+13) | 2.14 | 2.1 | NRSP52.3EP | 4P | 42 | 7.2 | - | 27 | 3 | 2.5 | 5 | 0(4) | 010 | f | |
| .. | G5(G4+13) | 2.14 | 2.1 | NRSP52.3EB | 2P | 42 | 7.2 | - | 27 | 3 | 2.5 | 5 | 0(4) | 010 | f | LONG |
| G6(G4+26) | 2.16 | 2.11 | NRSP62.3EP | 4P | 42 | 7.2 | - | 27 | 3 | 2.5 | 5 | 0(4) | 010 | f | ||
| G6(G4+26) | 2.16 | 2.11 | NRSP62.3EB | 2P | 42 | 7.2 | - | 27 | 3 | 2.5 | 5 | 0(4) | 010 | f | ||
| G5 | 2.32 | 2.27 | NRSP52.5FP | 4P | 46 | 8.1 | 14 | 29 | 3 | 2.5 | 5 | 0(4) | 012 | f | HAND | |
| G5 | 2.32 | 2.27 | NRSP52.5FB | 2P | 46 | 8.1 | 14 | 29 | 3 | 2.5 | 5 | 0(4) | 012 | f | TAPS | |
| M2.5X0.45 | G6(G5+13) | 2.34 | 2.29 | NRSP62.5FP | 4P | 46 | 8.1 | 14 | 29 | 3 | 2.5 | 5 | 0(4) | 012 | f | |
| G6(G5+13) | 2.34 | 2.29 | NRSP62.5FB | 2P | 46 | 8.1 | 14 | 29 | 3 | 2.5 | 5 | 0(4) | 012 | f | ||
| G5 | 2.42 | 2.37 | NRSP52.6FP | 4P | 46 | 8.1 | 14 | 29 | 3 | 2.5 | 5 | 0(4) | 012 | f | EG (STI) | |
| G5 | 2.42 | 2.37 | NRSP52.6FB | 2P | 46 | 8.1 | 14 | 29 | 3 | 2.5 | 5 | 0(4) | 012 | f | ||
| M2.6X0.45 | G6(G5+13) | 2.44 | 2.39 | NRSP62.6FP | 4P | 46 | 8.1 | 14 | 29 | 3 | 2.5 | 5 | 0(4) | 012 | f | |
| G6(G5+13) | 2.44 | 2.39 | NRSP62.6FB | 2P | 46 | 8.1 | 14 | 29 | 3 | 2.5 | 5 | 0(4) | 012 | f | SPECIAL | |
| G5 | 2.8 | 2.75 | NRSP53.0GP | 4P | 46 | 9 | 14 | 26 | 4 | 3.2 | 6 | 1(4) | 012 | f | THREADS, GAUGES | |
| G5 | 2.8 | 2.75 | NRSP53.0GB | 2P | 46 | 9 | 14 | 26 | 4 | 3.2 | 6 | 1(4) | 012 | f | ||
| G6(G5+13) | 2.82 | 2.76 | NRSP63.0GP | 4P | 46 | 9 | 14 | 26 | 4 | 3.2 | 6 | 1(4) | 012 | f | ||
| G6(G5+13) | 2.82 | 2.76 | NRSP63.0GB | 2P | 46 | 9 | 14 | 26 | 4 | 3.2 | 6 | 1(4) | 012 | f | THREAD | |
| M3X0.5 | G7(G5+26) | 2.83 | 2.77 | NRSP73.0GP | 4P | 46 | 9 | 14 | 26 | 4 | 3.2 | 6 | 1(4) | 012 | f | MILLS |
| G7(G5+26) | 2.83 | 2.77 | NRSP73.0GB | 2P | 46 | 9 | 14 | 26 | 4 | 3.2 | 6 | 1(4) | 012 | f | ||
| G8(G5+39) | 2.84 | 2.79 | NRSP83.0GP | 4P | 46 | 9 | 14 | 26 | 4 | 3.2 | 6 | 1(4) | 012 | f | ||
| G8(G5+39) | 2.84 | 2.79 | NRSP83.0GB | 2P | 46 | 9 | 14 | 26 | 4 | 3.2 | 6 | 1(4) | 012 | f | DIES | |
| G5 | 3.25 | 3.19 | NRSP53.5HP | 4P | 52 | 11 | 16 | 29 | 5 | 4 | 7 | 1(4) | 012 | f | ||
| G5 | 3.25 | 3.19 | NRSP53.5HB | 2P | 52 | 11 | 16 | 29 | 5 | 4 | 7 | 1(4) | 012 | f | ||
| M3.5X0.6 | G6(G5+13) | 3.26 | 3.2 | NRSP63.5HP | 4P | 52 | 11 | 16 | 29 | 5 | 4 | 7 | 1(4) | 012 | f | CENTER |
| G6(G5+13) | 3.26 | 3.2 | NRSP63.5HB | 2P | 52 | 11 | 16 | 29 | 5 | 4 | 7 | 1(4) | 012 | f | DRILLS | |
| G7(G5+26) | 3.28 | 3.21 | NRSP73.5HP | 4P | 52 | 11 | 16 | 29 | 5 | 4 | 7 | 1(4) | 012 | f |
