| MF | TCTR (tolerance) | Ø (mm) | Hole Ø (mm) | Code | THCHT (chamfer) | LF ( mm ) | THL ( mm ) | LU ( mm ) | LS ( mm ) | DCON ( mm ) | K ( mm ) | LK ( mm ) | NOF | Type | Stock |
| JIS | |||||||||||||||
| M12X15 | P4 | 10.5 | 10.6 | TY012OSLEN5 | 5P | 82 | 26 | - | 42 | 8.5 | 6.5 | 9 | 4 | 002 | f |
| . | P4 | 10.5 | 10.6 | TY012OSLENA | 1.5P | 82 | 26 | - | 42 | 8.5 | 6.5 | 9 | 4 | 002 | f |
| M12X125 | P4 | 10.8 | 10.85 | TY012NSLEN5 | 5P | 82 | 26 | - | 42 | 8.5 | 6.5 | 9 | 4 | 002 | f |
| . | P4 | 10.8 | 10.85 | TY012NSLENA | 1.5P | 82 | 26 | - | 42 | 8.5 | 6.5 | 9 | 4 | 002 | f |
| M12X1 | P3 | 11 | 11.09 | TY012MRLEN5 | 5P | 82 | 26 | - | 42 | 8.5 | 6.5 | 9 | 4 | 002 | f |
| P3 | 11 | 11.09 | TY012MRLENA | 1.5P | 82 | 26 | - | 42 | 8.5 | 6.5 | 9 | 4 | 002 | f | |
| M14X15 | P4 | 12.5 | 12.6 | TY014OSLEN5 | 5P | 88 | 26 | - | 45 | 10.5 | 8 | 11 | 4 | 002 | f |
| . | P4 | 12.5 | 12.6 | TY014OSLENA | 1.5P | 88 | 26 | - | 45 | 10.5 | 8 | 11 | 4 | 002 | f |
| M16X15 | P4 | 14.5 | 14.6 | TY016OSLEN5 | 5P | 95 | 26 | - | 48 | 12.5 | 10 | 13 | 4 | 002 | f |
| . | P4 | 14.5 | 14.6 | TY016OSLENA | 1.5P | 95 | 26 | - | 48 | 12.5 | 10 | 13 | 4 | 002 | f |
| M18X15 | P4 | 16.5 | 16.6 | TY018OSLEN5 | 5P | 100 | 33 | - | 51 | 14 | 11 | 14 | 4 | 002 | f |
| . | P4 | 16.5 | 16.6 | TY018OSLENA | 1.5P | 100 | 33 | - | 51 | 14 | 11 | 14 | 4 | 002 | f |
| M20X15 | P4 | 18.5 | 18.6 | TY020OSLEN5 | 5P | 105 | 33 | - | 50 | 15 | 12 | 15 | 4 | 002 | f |
| . | P4 | 18.5 | 18.6 | TY020OSLENA | 1.5P | 105 | 33 | - | 50 | 15 | 12 | 15 | 4 | 002 | f |
| M22X1.5 | P4 | 20.5 | 20.6 | TY022OSLENA | 1.5P | 115 | 33 | - | 55 | 17 | 13 | 16 | 4 | 002 | f |
| M24X1.5 | P4 | 22.5 | 22.6 | TY024OSLENA | 1.5P | 120 | 39 | - | 55 | 19 | 15 | 18 | 4 | 002 | f |
