Oversized h stock standard, ) check stock EU, f check stock JP, m stock exhaustion UNF TCTR Ø Hole Ø(tolerance)(mm)(mm)CodeTHCHT(chamfer)LF(mm)THL(mm) LU(mm) LS DCON K(mm)(mm)(mm)LK(mm)NOFTypeStock Intro JIS P2 3.5 3.55 TNMQUN8I5 5P 60 13 21 33 5.5 4.5 7 4 001 f No.8-36UNF P2 3.5 3.55 TNMQUN8I1 1.5P 60 13 21 33 5.5 4.5 7 4 001 f SP P3(P2+20) 3.5 3.55 TNMRUN8I5 5P 60 13 21 33 5.5 4.5 7 4 001 f P3(P2+20) 3.5 3.55 TNMRUN8I1 1.5P 60 13 21 33 5.5 4.5 7 4 001 f P2 4.1 4.12 TNMQUNAJ5 5P 60 13 22 33 5.5 4.5 7 4 001 f P2 4.1 4.12 TNMQUNAJ1 1.5P 60 13 22 33 5.5 4.5 7 4 001 f SL No.10-32UNF P3(P2+20) 4.1 4.12 TNMRUNAJ5 5P 60 13 22 33 5.5 4.5 7 4 001 f P3(P2+20) 4.1 4.12 TNMRUNAJ1 1.5P 60 13 22 33 5.5 4.5 7 4 001 f P2 4.6 4.67 TNMQUNCK5 5P 62 15 26 33 6 4.5 7 4 001 f PO P2 4.6 4.67 TNMQUNCK1 1.5P 62 15 26 33 6 4.5 7 4 001 f No.12-28UNF P3(P2+20) 4.6 4.67 TNMRUNCK5 5P 62 15 26 33 6 4.5 7 4 001 f P3(P2+20) 4.6 4.67 TNMRUNCK1 1.5P 62 15 26 33 6 4.5 7 4 001 f P2 5.5 5.53 TNMQU04K5 5P 62 15 26 33 6 4.5 7 4 001 f ST 1/4-28UNF P2 5.5 5.53 TNMQU04K1 1.5P 62 15 26 33 6 4.5 7 4 001 f JIS P4(P2+40) 5.5 5.53 TNMSU04K5 5P 62 15 26 33 6 4.5 7 4 001 f P4(P2+40) 5.5 5.53 TNMSU04K1 1.5P 62 15 26 33 6 4.5 7 4 001 f P2 6.9 6.97 TNMQU05M5 5P 70 19 - 36 6.2 5 8 4 002 f ROLL P2 6.9 6.97 TNMQU05M1 1.5P 70 19 - 36 6.2 5 8 4 002 f 5/16-24UNF P4(P2+40) 6.9 6.97 TNMSU05M5 5P 70 19 - 36 6.2 5 8 4 002 f P4(P2+40) 6.9 6.97 TNMSU05M1 1.5P 70 19 - 36 6.2 5 8 4 002 f CARBIDE P3 8.5 8.57 TNMRU06M5 5P 75 23 - 38 7 5.5 8 4 002 f P3 8.5 8.57 TNMRU06M1 1.5P 75 23 - 38 7 5.5 8 4 002 f 3/8-24UNF P4(P3+20) 8.5 8.57 TNMSU06M5 5P 75 23 - 38 7 5.5 8 4 002 f P4(P3+20) 8.5 8.57 TNMSU06M1 1.5P 75 23 - 38 7 5.5 8 4 002 f LONG P3 9.9 9.96 TNMRU07N5 5P 82 26 - 42 8.5 6.5 9 4 002 f P3 9.9 9.96 TNMRU07N1 1.5P 82 26 - 42 8.5 6.5 9 4 002 f 7/16-20UNF P4(P3+20) 9.9 9.96 TNMSU07N5 5P 82 26 - 42 8.5 6.5 9 4 002 f HAND P4(P3+20) 9.9 9.96 TNMSU07N1 1.5P 82 26 - 42 8.5 6.5 9 4 002 f TAPS P3 11.5 11.54 TNMRU08N5 5P 88 26 - 45 10.5 8 11 4 002 f P3 11.5 11.54 TNMRU08N1 1.5P 88 26 - 45 10.5 8 11 4 002 f 1/2-20UNF P4(P3+20) 11.5 11.54 TNMSU08N5 5P 88 26 - 45 10.5 8 11 4 002 f EG (STI) P4(P3+20) 11.5 11.54 TNMSU08N1 1.5P 88 26 - 45 10.5 8 11 4 002 f P3 12.9 13 TNMRU09O5 5P 95 26 - 48 12.5 10 13 4 002 f P3 12.9 13 TNMRU09O1 1.5P 95 26 - 48 12.5 10 13 4 002 f SPECIAL 9/16-18UNF P4(P3+20) 12.9 13 TNMSU09O5 5P 95 26 - 48 12.5 10 13 4 002 f THREADS,GAUGES P4(P3+20) 12.9 13 TNMSU09O1 1.5P 95 26 - 48 12.5 10 13 4 002 f P3 14.5 14.6 TNMRU10O5 5P 95 26 - 48 12.5 10 13 4 002 f P3 14.5 14.6 TNMRU10O1 1.5P 95 26 - 48 12.5 10 13 4 002 f THREAD 5/8-18UNF P4(P3+20) 14.5 14.6 TNMSU10O5 5P 95 26 - 48 12.5 10 13 4 002 f MILLS P4(P3+20) 14.5 14.6 TNMSU10O1 1.5P 95 26 - 48 12.5 10 13 4 002 f P3 17.5 17.59 TNMRU12P5 5P 105 33 - 50 15 12 15 4 002 f P3 17.5 17.59 TNMRU12P1 1.5P 105 33 - 50 15 12 15 4 002 f DIES 3/4-16UNF P4(P3+20) 17.5 17.59 TNMSU12P5 5P 105 33 - 50 15 12 15 4 002 f P4(P3+20) 17.5 17.59 TNMSU12P1 1.5P 105 33 - 50 15 12 15 4 002 f 7/8-14UNF P4 20.5 20.57 TNMSU14Q5 5P 115 33 - 55 17 13 16 4 002 f CENTERP420.520.57TNMSU14Q11.5P11533-551713164002fDRILLS Technical info 315
