| MF | TCTR (tolerance) | Ø (mm) | Hole Ø (mm) | Code | THCHT (chamfer) | LF ( mm ) | THL ( mm ) | LU ( mm ) | LS ( mm ) | DCON ( mm ) | K ( mm ) | LK ( mm ) | NOF | Type | Stock | Intro |
| JIS | ||||||||||||||||
| P2 | 7 | 7.09 | TNMQ8.0M5 | 5P | 70 | 19 | - | 36 | 6.2 | 5 | 8 | 4 | 002 | f | ||
| P2 | 7 | 7.09 | TNMQ8.0M1 | 1.5P | 70 | 19 | - | 36 | 6.2 | 5 | 8 | 4 | 002 | ) | SP | |
| P4(P2+40) | 7 | 7.09 | TNMS8.0M5 | 5P | 70 | 19 | - | 36 | 6.2 | 5 | 8 | 4 | 002 | f | ||
| M8X1 | P4(P2+40) | 7 | 7.09 | TNMS8.0M1 | 1.5P | 70 | 19 | - | 36 | 6.2 | 5 | 8 | 4 | 002 | f | |
| P2 | 7 | 7.09 | TNMQ8.0M5T | 5P | 70 | 19 | - | 36 | 6.2 | 5 | 8 | 3 | 002 | f | ||
| P2 | 7 | 7.09 | TNMQ8.0M1T | 1.5P | 70 | 19 | - | 36 | 6.2 | 5 | 8 | 3 | 002 | f | SL | |
| P3(P2+20) | 7 | 7.09 | TNMR8.0M5 | 5P | 70 | 19 | - | 36 | 6.2 | 5 | 8 | 4 | 002 | f | ||
| P3(P2+20) | 7 | 7.09 | TNMR8.0M1 | 1.5P | 70 | 19 | - | 36 | 6.2 | 5 | 8 | 4 | 002 | f | ||
| M8X075 | P2 | 7.3 | 7.33 | TNMQ8.0J5 | 5P | 70 | 19 | - | 36 | 6.2 | 5 | 8 | 4 | 002 | f | PO |
| . | P2 | 7.3 | 7.33 | TNMQ8.0J1 | 1.5P | 70 | 19 | - | 36 | 6.2 | 5 | 8 | 4 | 002 | ) | |
| P2 | 7.5 | 7.56 | TNMQ8.0G5 | 5P | 70 | 10 | - | 36 | 6.2 | 5 | 8 | 4 | 037 | f | ||
| M8X0.5 | P2 | 7.5 | 7.56 | TNMQ8.0G1 | 1.5P | 70 | 10 | - | 36 | 6.2 | 5 | 8 | 4 | 037 | ) | |
| P2 | 7.5 | 7.59 | TNMQ8.5M5 | 5P | 75 | 23 | - | 38 | 7 | 5.5 | 8 | 4 | 002 | f | ST | |
| M8.5X1 | P2 | 7.5 | 7.59 | TNMQ8.5M1 | 1.5P | 75 | 23 | - | 38 | 7 | 5.5 | 8 | 4 | 002 | f | JIS |
| P2 | 7.8 | 7.81 | TNMQ8.5J5 | 5P | 75 | 13 | - | 38 | 7 | 5.5 | 8 | 4 | 037 | f | ||
| M8.5X0.75 | P2 | 7.8 | 7.81 | TNMQ8.5J1 | 1.5P | 75 | 13 | - | 38 | 7 | 5.5 | 8 | 4 | 037 | f | ROLL |
| M85X05 | P2 | 8 | 8.06 | TNMQ8.5G5 | 5P | 75 | 11 | - | 38 | 7 | 5.5 | 8 | 4 | 037 | f | |
| .. | P2 | 8 | 8.06 | TNMQ8.5G1 | 1.5P | 75 | 11 | - | 38 | 7 | 5.5 | 8 | 4 | 037 | f | |
| M9X1 | P2 | 8 | 8.09 | TNMQ9.0M5 | 5P | 75 | 23 | - | 38 | 7 | 5.5 | 8 | 4 | 002 | f | |
| P2 | 8 | 8.09 | TNMQ9.0M1 | 1.5P | 75 | 23 | - | 38 | 7 | 5.5 | 8 | 4 | 002 | ) | CARBIDE | |
| P2 | 8.3 | 8.33 | TNMQ9.0J5 | 5P | 75 | 13 | - | 38 | 7 | 5.5 | 8 | 4 | 037 | f | ||
| M9X0.75 | P2 | 8.3 | 8.33 | TNMQ9.0J1 | 1.5P | 75 | 13 | - | 38 | 7 | 5.5 | 8 | 4 | 037 | f | |
| M9X05 | P2 | 8.5 | 8.56 | TNMQ9.0G5 | 5P | 75 | 11 | - | 38 | 7 | 5.5 | 8 | 4 | 037 | f | |
| . | P2 | 8.5 | 8.56 | TNMQ9.0G1 | 1.5P | 75 | 11 | - | 38 | 7 | 5.5 | 8 | 4 | 037 | f | LONG |
| MX | P2 | 8.5 | 8.59 | TNMQ9.5M5 | 5P | 75 | 23 | - | 38 | 7 | 5.5 | 8 | 4 | 002 | f | |
| 9.51 | P2 | 8.5 | 8.59 | TNMQ9.5M1 | 1.5P | 75 | 23 | - | 38 | 7 | 5.5 | 8 | 4 | 002 | f | |
| P2 | 8.8 | 8.83 | TNMQ9.5J5 | 5P | 75 | 13 | - | 38 | 7 | 5.5 | 8 | 4 | 037 | f | HAND | |
| M9.5X0.75 | P2 | 8.8 | 8.83 | TNMQ9.5J1 | 1.5P | 75 | 13 | - | 38 | 7 | 5.5 | 8 | 4 | 037 | f | TAPS |
| P2 | 9 | 9.06 | TNMQ9.5G5 | 5P | 75 | 11 | - | 38 | 7 | 5.5 | 8 | 4 | 037 | f | ||
| M9.5X0.5 | P2 | 9 | 9.06 | TNMQ9.5G1 | 1.5P | 75 | 11 | - | 38 | 7 | 5.5 | 8 | 4 | 037 | f | |
| P3 | 8.8 | 8.85 | TNMR010N5 | 5P | 75 | 23 | - | 38 | 7 | 5.5 | 8 | 4 | 002 | f | EG (STI) | |
| P3 | 8.8 | 8.85 | TNMR010N1 | 1.5P | 75 | 23 | - | 38 | 7 | 5.5 | 8 | 4 | 002 | ) | ||
| P4(P3+20) | 8.8 | 8.85 | TNMS010N5 | 5P | 75 | 23 | - | 38 | 7 | 5.5 | 8 | 4 | 002 | f | ||
| M10X125 | P4(P3+20) | 8.8 | 8.85 | TNMS010N1 | 1.5P | 75 | 23 | - | 38 | 7 | 5.5 | 8 | 4 | 002 | f | SPECIAL |
| . | P3 | 8.8 | 8.85 | TNMR010N5T | 5P | 75 | 23 | - | 38 | 7 | 5.5 | 8 | 3 | 002 | f | THREADS, GAUGES |
| P3 | 8.8 | 8.85 | TNMR010N1T | 1.5P | 75 | 23 | - | 38 | 7 | 5.5 | 8 | 3 | 002 | f | ||
| P5(P3+40) | 8.8 | 8.85 | TNMT010N5 | 5P | 75 | 23 | - | 38 | 7 | 5.5 | 8 | 4 | 002 | f | ||
| P5(P3+40) | 8.8 | 8.85 | TNMT010N1 | 1.5P | 75 | 23 | - | 38 | 7 | 5.5 | 8 | 4 | 002 | f | THREAD | |
| P3 | 9 | 9.09 | TNMR010M5 | 5P | 75 | 23 | - | 38 | 7 | 5.5 | 8 | 4 | 002 | f | MILLS | |
| P3 | 9 | 9.09 | TNMR010M1 | 1.5P | 75 | 23 | - | 38 | 7 | 5.5 | 8 | 4 | 002 | ) | ||
| M10X1 | P4(P3+20) | 9 | 9.09 | TNMS010M5 | 5P | 75 | 23 | - | 38 | 7 | 5.5 | 8 | 4 | 002 | f | |
