| UNF | TCTR (tolerance) | Ø (mm) | Hole Ø (mm) | Code | THCHT (chamfer) | LF ( inch ) ( in | LT ch ) THL ( inch ) | LU ( inch ) ( i | L nc | S h ) DCON ( inch ) K ( inch ) LK ( inch ) | NOF Type | Stock | Intro |
| ANSI | |||||||||||||
| GH3 | 6.9 | 6.97 | Y84616 | 2.5P | 2.718 | - 0.394 | 1.125 | - | 0.32 0.238 0.375 | 3 002 | f | ||
| GH3 | 6.9 | 6.97 | Y84016 | 1.5P | 2.718 | - 0.394 | 1.125 | - | 0.32 0.238 0.375 | 3 002 | f | SP | |
| 5/1624UNF | GH4 | 6.9 | 6.97 | Y84632 | 2.5P | 2.718 | - 0.394 | 1.125 | - | 0.32 0.238 0.375 | 3 002 | f | ANSI |
| - | GH5 | 6.9 | 6.97 | Y84646 | 2.5P | 2.718 | - 0.394 | 1.125 | - | 0.32 0.238 0.375 | 3 002 | f | |
| GH5 | 6.9 | 6.97 | Y84046 | 2.5P | 2.718 | - 0.394 | 1.125 | - | 0.32 0.238 0.375 | 3 002 | f | ||
| GH7 | 6.9 | 6.97 | Y84676 | 2.5P | 2.718 | - 0.394 | 1.125 | - | 0.32 0.238 0.375 | 3 002 | f | SL | |
| GH3 | 8.5 | 8.57 | Y84618 | 2.5P | 2.937 | - 0.394 | 1.25 | - | 0.38 0.286 0.437 | 3 002 | f | ||
| GH3 | 8.5 | 8.57 | Y84018 | 1.5P | 2.937 | - 0.394 | 1.25 | - | 0.38 0.286 0.437 | 3 002 | f | ||
| GH4 | 8.5 | 8.57 | Y84633 | 2.5P | 2.937 | - 0.394 | 1.25 | - | 0.38 0.286 0.437 | 3 002 | f | PO | |
| 3/8-24UNF | GH4 | 8.5 | 8.57 | Y84033 | 1.5P | 2.937 | - 0.394 | 1.25 | - | 0.38 0.286 0.437 | 3 002 | f | |
| GH5 | 8.5 | 8.57 | Y84648 | 2.5P | 2.937 | - 0.394 | 1.25 | - | 0.38 0.286 0.437 | 3 002 | f | ||
| GH5 | 8.5 | 8.57 | Y84048 | 1.5P | 2.937 | - 0.394 | 1.25 | - | 0.38 0.286 0.437 | 3 002 | f | ||
| GH7 | 8.5 | 8.57 | Y84678 | 2.5P | 2.937 | - 0.394 | 1.25 | - | 0.38 0.286 0.437 | 3 002 | f | ST | |
| GH3 | 9.9 | 9.96 | Y84620 | 2.5P | 3.156 | - 0.472 | - | - | 0.32 0.242 0.406 | 3 014 | f | ||
| GH3 | 9.9 | 9.96 | Y84020 | 1.5P | 3.156 | - 0.472 | - | - | 0.32 0.242 0.406 | 3 014 | f | ||
| 7/16-20UNF | GH5 | 9.9 | 9.96 | Y84650 | 2.5P | 3.156 | - 0.472 | - | - | 0.32 0.242 0.406 | 3 014 | f | ROLL |
| GH5 | 9.9 | 9.96 | Y84050 | 1.5P | 3.156 | - 0.472 | - | - | 0.32 0.242 0.406 | 3 014 | f | ||
| GH6 | 9.9 | 9.96 | Y84691 | 2.5P | 3.156 | - 0.472 | - | - | 0.32 0.242 0.406 | 3 014 | f | ||
| GH7 | 9.9 | 9.96 | Y84680 | 2.5P | 3.156 | - 0.472 | - | - | 0.32 0.242 0.406 | 3 014 | f | ||
| GH3 | 11.5 | 11.54 | Y84622 | 2.5P | 3.375 | - 0.472 | - | - | 0.37 0.275 0.437 | 3 014 | f | CARBIDE | |
| GH3 | 11.5 | 11.54 | Y84022 | 1.5P | 3.375 | - 0.472 | - | - | 0.37 0.275 0.437 | 3 014 | f | ||
| GH5 | 11.5 | 11.54 | Y84652 | 2.5P | 3.375 | - 0.472 | - | - | 0.37 0.275 0.437 | 3 014 | f | ||
| 1/2-20UNF | GH5 | 11.5 | 11.54 | Y84052 | 1.5P | 3.375 | - 0.472 | - | - | 0.37 0.275 0.437 | 3 014 | f | |
| GH6 | 11.5 | 11.54 | Y84692 | 2.5P | 3.375 | - 0.472 | - | - | 0.37 0.275 0.437 | 3 014 | f | LONG | |
| GH7 | 11.5 | 11.54 | Y84682 | 2.5P | 3.375 | - 0.472 | - | - | 0.37 0.275 0.437 | 3 014 | f | ||
| GH3 | 12.9 | 13 | Y84654 | 2.5P | 3.593 | - 0.512 | - | - | 0.43 0.322 0.5 | 3 014 | f | ||
| 9/16-18UNF | GH3 | 12.9 | 13 | Y84054 | 1.5P | 3.593 | - 0.512 | - | - | 0.43 0.322 0.5 | 3 014 | f | HAND |
| GH5 | 12.9 | 13 | Y84698 | 2.5P | 3.593 | - 0.512 | - | - | 0.43 0.322 0.5 | 3 014 | f | TAPS | |
| GH3 | 14.5 | 14.6 | Y84626 | 2.5P | 3.812 | - 0.512 | - | - | 0.48 0.36 0.562 | 3 014 | f | ||
| GH3 | 14.5 | 14.6 | Y84026 | 1.5P | 3.812 | - 0.512 | - | - | 0.48 0.36 0.562 | 3 014 | f | ||
| 5/8-18UNF | GH5 | 14.5 | 14.6 | Y84656 | 2.5P | 3.812 | - 0.512 | - | - | 0.48 0.36 0.562 | 3 014 | f | EG (STI) |
| GH5 | 14.5 | 14.6 | Y84056 | 1.5P | 3.812 | - 0.512 | - | - | 0.48 0.36 0.562 | 3 014 | f | ||
| GH7 | 14.5 | 14.6 | Y84672 | 2.5P | 3.812 | - 0.512 | - | - | 0.48 0.36 0.562 | 3 014 | f | ||
| GH3 | 17.5 | 17.59 | Y84628 | 2.5P | 4.25 | - 0.591 | - | - | 0.59 0.442 0.687 | 4 014 | f | SPECIAL | |
| GH3 | 17.5 | 17.59 | Y84028 | 1.5P | 4.25 | - 0.591 | - | - | 0.59 0.442 0.687 | 4 014 | f | THREADS, GAUGES | |
| 3/4-16UNF | |||||||||||||
| GH5 | 17.5 | 17.59 | Y84658 | 2.5P | 4.25 | - 0.591 | - | - | 0.59 0.442 0.687 | 4 014 | f | ||
| GH7 | 17.5 | 17.59 | Y84686 | 2.5P | 4.25 | - 0.591 | - | - | 0.59 0.442 0.687 | 4 014 | f | ||
| GH4 | 20.5 | 20.57 | Y84696 | 2.5P | 4.687 | - 0.709 | - | - | 0.7 0.523 0.75 | 4 014 | f | THREAD | |
| 7/8-14UNF | GH6 | 20.5 | 20.57 | Y84694 | 2.5P | 4.687 | - 0.709 | - | - | 0.7 0.523 0.75 | 4 014 | f | MILLS |
| 1 -12UNF | GH4 | 23.3 | 23.46 | Y84668 | 2.5P | 5.125 | - 0.709 | - | - | 0.8 0.6 0.812 | 4 014 | f | |
| 1 1/8-12UNF | GH5 | 26.5 | 26.63 | Y84702 | 2.5P | 5.437 | - 0.787 | - | - | 0.9 0.672 0.875 | 4 014 | f | |
| 1 1/4-12UNF | GH5 | 29.6 | 29.81 | Y84705 | 2.5P | 5.75 | - 0.787 | - | - | 1.02 0.766 1 | 4 014 | f | DIES |
| 1 3/8-12UNF | GH5 | 32.8 | 32.98 | Y84707 | 2.5P | 6.062 | - 0.787 | - | - | 1.11 0.831 1.062 | 4 014 | f | |
| 1 1/2-12UNF | GH5 | 36 | 36.16 | Y84711 | 2.5P | 6.375 | - 0.787 | - | - | 1.23 0.925 1.125 | 4 014 | f |
