ᅚARCO coating provides a superior wear resistance. ᅚSuitable for HRC 50 and over HRC 50 Hardened Steel, also maximum up to HRC 65. ᅚ$YDLODEOHLQYDULRXVHႇHFWLYHFXWWLQJOHQJWKV ᅚIt is suitable for deep cutting. ᅚ7KHFRDWLQJFDQFKDQJHWR6,&2WKHSULFHVZLOOGLႇHU

Order No. ����Dia. (d)Corner Radius (R)CL (L1)EFF-L (L2)OAL (L)Shank (D)Flutes (F)
EHCRC20500116A5.00.1R5.0166062
EHCRC20500130A5.00.1R5.0307562
EHCRC20500216A5.00.2R5.0166062
EHCRC20500230A5.00.2R5.0307562
EHCRC20500316A5.00.3R5.0166062
EHCRC20500330A5.00.3R5.0307562
EHCRC20500516A5.00.5R5.0166062
EHCRC20500530A5.00.5R5.0307562
EHCRC20501016A5.01.0R5.0166062
EHCRC20501030A5.01.0R5.0307562
EHCRC20600120A6.00.1R7.0206062
EHCRC20600130A6.00.1R7.0307562
EHCRC20600220A6.00.2R7.0206062
EHCRC20600230A6.00.2R7.0307562
EHCRC20600320A6.00.3R7.0206062
EHCRC20600330A6.00.3R7.0307562
EHCRC20600520A6.00.5R7.0206062
EHCRC20600530A6.00.5R7.0307562
EHCRC20601020A6.01.0R7.0206062
EHCRC20601030A6.01.0R7.0307562
EHCRC20601520A6.01.5R7.0206062
EHCRC20601530A6.01.5R7.0307562
EHCRC20800522A8.00.5R9.0226082
EHCRC20801022A8.01.0R9.0226082
EHCRC20801522A8.01.5R9.0226082
EHCRC20802022A8.02.0R9.0226082
EHCRC21000524A10.00.5R11.02475102
EHCRC21001024A10.01.0R11.02475102
EHCRC21001524A10.01.5R11.02475102
EHCRC21002024A10.02.0R11.02475102
EHCRC21200526A12.00.5R13.02675122
EHCRC21201026A12.01.0R13.02675122
EHCRC21201526A12.01.5R13.02675122
EHCRC21202026A12.02.0R13.02675122

EHCRC

d R

L1

L2

L

D

dToleranceEHCRC21202026A 12
Ø0 ~ 0.02
�����R ± 0.015
R > 2R ± 0.020✽ is ARCO Coating

is SICO Coating
