Solid Carbide Drills Solid Carbide Drills DTN - Tip angle 120° (for Spotting) 㜃汣䧻幹▗捠⪥⍆⴩⃜昌 P M K N S H Product Specs 虉120° Tip Angle 虉60° Chamfer Angle 虉External Coolant 虉UNIX Coating β β β ΰ ΰ β 虉Tolerance h8 虉For steel, stainless steel, cast iron, pre-hardened steel, from HRC 20 to HRC 60 materials. Unit:mm Order No. D L1 L Ds Order No. D L1 L Ds 宑庋佷䩋 宑庋佷䩋 DTN03001201 3.00 8 50 3 ρ Long Shank Type DTN04001201 4.00 10 50 4 DTN04001211 4.00 10 75 4 DTN05001201 5.00 13 50 5 DTN05001211 5.00 13 75 5 DTN06001201 6.00 15 50 6 DTN06001211 6.00 15 100 6 DTN08001201 8.00 20 60 8 DTN08001211 8.00 20 100 8 DTN10001201 10.00 25 75 10 DTN10001211 10.00 25 150 10 DTN12001201 12.00 30 75 12 DTN12001211 12.00 30 150 12 DTN16001201 16.00 35 100 16 DTN16001211 16.00 35 150 16 Cutting conditions ( ⎖⏙㨬₅㜇㙩姷 ) : Page SB060 SB049
