Solid Carbide Drills DPC9 - 15×D 㜃汣䧻幹▗捠⋶⍆昌 P M K N S H Product Specs 虉15×D Cutting depth 虉Reinforced Shank 虉135° Tip Angle 虉Internal Coolant β ΰ β ΰ 虉UNIX Coating 虉Tolerance h8 虉Double Margins Design 虉SX Design 虉For Steel, Alloy Steel, Stainless Steel and Cast Iron. ʰRequire an initial pilot hole to guide the drill. Unit:mm Order No. D L1 L Ds Order No. D L1 L Ds 宑庋佷䩋 宑庋佷䩋 DPC903001501 3.00 55 95 4 DPC903501501 3.50 76 116 4 DPC904001501 4.00 76 116 4 DPC904501501 4.50 93 133 6 DPC905001501 5.00 93 133 6 DPC905501501 5.50 110 150 6 DPC906001501 6.00 110 150 6 DPC906501501 6.50 127 167 8 DPC907001501 7.00 127 167 8 DPC907501501 7.50 143 183 8 DPC908001501 8.00 143 183 8 DPC908501501 8.50 160 204 10 DPC909001501 9.00 160 204 10 DPC909501501 9.50 177 221 10 DPC910001501 10.00 177 221 10 DPC911001501 11.00 198 247 12 DPC912001501 12.00 214 263 12 ρ Minimum order quantity is required 㢏⃝宑庋捞柟⏅ Cutting conditions ( ⎖⏙㨬₅㜇㙩姷 ) : Page SB059 SB012
