Solid Carbide Endmills G550 - High Helix Corner Radius Type - 4F 㜃汣䧻幹▗捠⢢烊搠⎏ . 汧⶝⤚ .!4 ⎒ ᅚ 81,&2&RDWLQJSURYLGHVVXSHULRUZHDUUHVLVWDQFHDQGUHGXFHVWKHFRHႈFLHQWRIIULFWLRQ ᅚ Suitable for HRC 30 to HRC 55 Ordinary Steel, Alloy Steel, Cast Iron, Heat-Resistant Steel, etc. ᅚ Corner radius with high helix angle improves the side milling quality. Order No. Dia. Corner CL OAL Shank Flutes 宑庋佷䩋 (d) Radius (L1) (L) (D) (F) (R) EPCSH EPCFH403005U 3.0 0.5R 6 50 4 4 EPCFH404005U 4.0 0.5R 8 50 4 4 EPCSH405005U 5.0 0.5R 10 50 6 4 EPCSH405010U 5.0 1.0R 10 50 6 4 EPCSH406005U 6.0 0.5R 12 50 6 4 EPCSH406010U 6.0 1.0R 12 50 6 4 d R EPCSH408005U 8.0 0.5R 16 60 8 4 EPCSH408010U 8.0 1.0R 16 60 8 4 EPCSH410005U 10.0 0.5R 20 75 10 4 L1 EPCSH410010U 10.0 1.0R 20 75 10 4 EPCSH410015U 10.0 1.5R 20 75 10 4 EPCSH410020U 10.0 2.0R 20 75 10 4 EPCSH412010U 12.0 1.0R 24 75 12 4 EPCSH412020U 12.0 2.0R 24 75 12 4 L EPCSH412030U 12.0 3.0R 24 75 12 4 D 45° Cutting conditions) ら峿⎖⏙╒㜇姷 * : Table 050 d R Tolerance Ø<3 0 ~ -0.03 3 Ŝ Ø Ŝ 10 0 ~ -0.04 Ø > 10 0 ~ -0.05 5” R ± 0.015 R>2 R ± 0.020 SA098
