Solid Carbide Endmills Solid Carbide Endmills G550 - Corner Radius Type - 4F 㜃汣䧻幹▗捠⢢烊搠⎏ . 㮨䀥⤚ .!4 ⎒ ᅚ 81,&2&RDWLQJSURYLGHVVXSHULRUZHDUUHVLVWDQFHDQGUHGXFHVWKHFRHႈFLHQWRIIULFWLRQ ᅚSuitable for HRC 30 to HRC 55 Ordinary Steel, Alloy Steel, Cast Iron, Heat-Resistant Steel, etc. ᅚ &RUQHUUDGLXVZLWKPXOWLSOHGHVLJQLQFUHDVHVWKH¿QLVKPLOOLQJVXUIDFH Order No.宑庋佷䩋 Dia. (d) CornerRadius(R)CL(L1) OAL Shank Flutes(L)(D)(F) EPCSC EPCFC401002U 1.0 0.2R 2 50 4 4 EPCFC401003U 1.0 0.3R 2 50 4 4 EPCFC401502U 1.5 0.2R 3 50 4 4 EPCFC401503U 1.5 0.3R 3 50 4 4 EPCFC401505U 1.5 0.5R 3 50 4 4 EPCFC402002U 2.0 0.2R 4 50 4 4 EPCFC402003U 2.0 0.3R 4 50 4 4 d R EPCFC402005U 2.0 0.5R 4 50 4 4 EPCTC403002U 3.0 0.2R 6 50 3 4 EPCFC403002U 3.0 0.2R 6 50 4 4 L1 EPCTC403003U 3.0 0.3R 6 50 3 4 EPCFC403003U 3.0 0.3R 6 50 4 4 EPCTC403005U 3.0 0.5R 6 50 3 4 EPCFC403005U 3.0 0.5R 6 50 4 4 EPCTC403010U 3.0 1.0R 6 50 3 4 EPCFC403010U 3.0 1.0R 6 50 4 4 L EPCFC404001U 4.0 0.1R 8 50 4 4 EPCFC404002U 4.0 0.2R 8 50 4 4 EPCFC404003U 4.0 0.3R 8 50 4 4 EPCFC404005U 4.0 0.5R 8 50 4 4 EPCFC404010U 4.0 1.0R 8 50 4 4 EPCSC403003U 3.0 0.3R 6 50 6 4 EPCSC403005U 3.0 0.5R 6 50 6 4 EPCSC403010U 3.0 1.0R 6 50 6 4 EPCSC404003U 4.0 0.3R 8 50 6 4 EPCSC404005U 4.0 0.5R 8 50 6 4 D EPCSC404010U 4.0 1.0R 8 50 6 4 EPCSC405005U 5.0 0.5R 10 50 6 4 EPCSC405010U 5.0 1.0R 10 50 6 4 EPCSC406003U 6.0 0.3R 12 50 6 4 EPCSC406005U 6.0 0.5R 12 50 6 4 EPCSC406010U 6.0 1.0R 12 50 6 4 EPCSC408005U 8.0 0.5R 16 60 8 4 EPCSC408010U 8.0 1.0R 16 60 8 4 EPCSC408015U 8.0 1.5R 16 60 8 4 EPCSC410005U 10.0 0.5R 20 75 10 4 EPCSC410010U 10.0 1.0R 20 75 10 4 EPCSC410015U 10.0 1.5R 20 75 10 4 EPCSC410020U 10.0 2.0R 20 75 10 4 d R Tolerance EPCSC412005U 12.0 0.5R 24 75 12 4 Ø<3 0 ~ -0.03 EPCSC412010U 12.0 1.0R 24 75 12 4 3 Ŝ Ø Ŝ 10 0 ~ -0.04 EPCSC412015U 12.0 1.5R 24 75 12 4 Ø > 10 0 ~ -0.05 EPCSC412020U 12.0 2.0R 24 75 12 4 5” R ± 0.015 EPCSC412030U 12.0 3.0R 24 75 12 4 R>2 R ± 0.020 Cutting conditions) ら峿⎖⏙╒㜇姷 * : Table 049 SA097
