Recommended Cutting Conditions

for WP26339R14

aw1 = (0.5D, 0.5D) aw2 = (0.25D, 0.25D)

Working Material Vc

fz

Carbon Steel (HB85-225)120 ~ 2500.16 ~ 0.300.2 ~ 0.39
Stainless 300 Series100 ~ 1800.08 ~ 0.140.1 ~ 0.18
Cast Iron (HB140-220)120 ~ 2500.16 ~ 0.300.2 ~ 0.39
High temp. & Titanium alloy40 ~ 1000.08 ~ 0.120.1 ~ 0.18

for WP26379R25

aw1 = (0.5D, 0.5D) aw2 = (0.25D, 0.25D)

Working Material Vc

fz

Carbon Steel (HB85-225)120 ~ 2500.20 ~ 0.360.26 ~ 0.46
Stainless 300 Series100 ~ 1800.08 ~ 0.140.10 ~ 0.18
Cast Iron (HB140-220)120 ~ 2500.20 ~ 0.360.26 ~ 0.46
High temp. & Titanium alloy40 ~ 1000.08 ~ 0.120.10 ~ 0.18

CF22M - Modular tools

Order No.

R D L1 L2 d M T Inserts

宑庋佷䩋 Screw Wrench

ICF22M20202512012.5R25214212.5M122
ICF22M20203012015R30235012.5M122WP26339R14 ITS4023ITK15
ICF22M20203216016R32235017.0M162
ICF22M20204018020R40386528.0M182

WP26379R25 ITS5007 ITK20

ICF22M202050250 25R 50 45 80 36.0 M25 2

Customize available.
