- Superior wall and surface finish capabilities.
- “Stepless” solution. True 90° to run precise applications in multiple axial passes.
- Strong concept to run up to 15mm (.590") depth of cut.
- Effective internal coolant feature, reaching the cutting edge precisely.
- Weldon Shanks
| order number | catalogue number | D1 | D | L | L2 | Ap1 max | Z kg | max RPM |
| 5710285 | VSM490D025Z02B25XN15 | 25 | 25 | 89 | 32 | 15,0 | 2 0,28 | 26700 |
| 5710286 | VSM490D032Z03B32XN15 | 32 | 32 | 111 | 50 | 15,0 | 3 0,58 | 22000 |
| 5873215 | VSM490D040Z03B32XN15 | 40 | 32 | 111 | 50 | 15,0 | 3 0,65 | 18800 |
NOTE: Weldon type not recommended for finishing operations.
- Spare Parts
insert Torx Plus
| screw | Nm | driver |
| MS-2071 | 3,5 | DT15IP |
