Общий каталог Widia 2017 - страница 800
Навигация
Каталог Widia токарный инструмент 2017
Каталог Widia трохоидальное фрезерование
Каталог Widia техническое руководство по разверткам
Каталог Widia фрезы со сменными пластинами 2016
Каталог Widia достижения 2020- Table of Contents
- Turning
- Turning • ISO Inserts
- Turning • Tools for External Turning and Internal Boring
- Turning • Tools for External Turning and Internal Boring
- Turning • Tools for Small Hole Boring
- com E1Turning • Grooving and Cut-Off
- Turning • Threading
- Indexable Milling
- Indexable Milling • Face Mills
- Indexable Milling • Chamfer Mills
- Indexable Milling • 90° Shoulder Mills
- Indexable Milling • Helical Mills
- Indexable Milling • Slotting Mills
- Indexable Milling • Copy Mills
- Solid End Milling
- Solid End Milling • High-Performance Solid Carbide End Mills
- Solid End Milling • General Purpose Solid Carbide End Mills
- Solid End Milling • High-Performance High-Speed Steel (HSS-E/PM)
- Solid End Milling • Burs
- Holemaking
- Holemaking • High-Performance Solid Carbide Drills
- Holemaking • Modular Drills
- Holemaking • Indexable Drills
- Holemaking • Modular Drills
- Holemaking • Indexable Drills
- Holemaking • Hole Finishing
- Tapping
- Tapping Portfolio
- Index by Order Number
- Index by Catalogue Number
- Global Contacts
- Informational Icons Guide
- Material Overview • DIN
- Chamfer milling in steel, stainless steel, and cast iron.
- Weldon Shanks
coolant
| order number | catalogue number | D | D1 | D1 max | L | L2 | Ap1 max | Z | insert 1 | supply | kg | |||
| 2022628 | 12292510400 | 16 | 16 | 28,8 | 75 | 27 | 6,4 | 2 | SD..0903.. | No | 0,10 | |||
| 2022629 | 12292510800 | 25 | 25 | 37,8 | 96 | 40 | 6,4 | 2 | SD..0903.. | No | 0,30 | |||
| 2022630 | 12292511000 | 32 | 32 | 44,8 | 100 | 40 | 6,4 | 3 | SD..0903.. | No | 0,50 |
- Spare Parts
insert Torx
screw Nm wrench
12148095100 3,0 12148000600
