Application Guide • 90° Shoulder Mills

90° Shoulder VSM11 ™ VSM490™-15

P P

Mills

Max depth of cut: 11,7mm M Max depth of cut: 15mm M

K K Lead angle: 90° Lead angle: 90° N Indexes per insert: 2 Indexes per insert: 4 S S Diameter: 16–125mm Diameter: 25–160mm H Pages: J4–J16 Pages: J32–J40

VSM17 ™ M690 SD1204.. P P

Max depth of cut: 16,33mm M Max depth of cut: 10mm M

K K Lead angle: 90° Lead angle: 90° N Indexes per insert: 2 Indexes per insert: 4 S S Diameter: 25–160mm Diameter: 50–160mm H Pages: J20–J29 Pages: J44–J47

M690 SD1506.. Max depth of cut: 12mm

Lead angle: 90° Indexes per insert: 4 Diameter: 50–125mm Pages: J48–J51

P M K

S H
