Общий каталог Widia 2017 - страница 655
Навигация
Каталог Widia токарный инструмент 2017
Каталог Widia трохоидальное фрезерование
Каталог Widia техническое руководство по разверткам
Каталог Widia фрезы со сменными пластинами 2016
Каталог Widia достижения 2020- Table of Contents
- Turning
- Turning • ISO Inserts
- Turning • Tools for External Turning and Internal Boring
- Turning • Tools for External Turning and Internal Boring
- Turning • Tools for Small Hole Boring
- com E1Turning • Grooving and Cut-Off
- Turning • Threading
- Indexable Milling
- Indexable Milling • Face Mills
- Indexable Milling • Chamfer Mills
- Indexable Milling • 90° Shoulder Mills
- Indexable Milling • Helical Mills
- Indexable Milling • Slotting Mills
- Indexable Milling • Copy Mills
- Solid End Milling
- Solid End Milling • High-Performance Solid Carbide End Mills
- Solid End Milling • General Purpose Solid Carbide End Mills
- Solid End Milling • High-Performance High-Speed Steel (HSS-E/PM)
- Solid End Milling • Burs
- Holemaking
- Holemaking • High-Performance Solid Carbide Drills
- Holemaking • Modular Drills
- Holemaking • Indexable Drills
- Holemaking • Modular Drills
- Holemaking • Indexable Drills
- Holemaking • Hole Finishing
- Tapping
- Tapping Portfolio
- Index by Order Number
- Index by Catalogue Number
- Global Contacts
- Informational Icons Guide
- Material Overview • DIN
| - — connue) | American UN-Interna | l | �first choice �alternate choice | P � M � K � N � S � H | |
| catalogue number | EX | E | insert size | thread pitch mm TPI | TPF TN6025 |
| 3IR12UN 3IR10UN | 1,1 1,1 | 1,4 1,5 | 3 3 | — 12 — 10 | — 2018966 — 2018979 |
| 3IR8UN left hand | 1,1 | 1,5 | 3 | — 8 | — 2018990 |
| 3IL64UN 3IL56UN | 0,8 0,7 | 0,4 0,4 | 3 3 | — 64 — 56 | — 3122416 — 3122414 |
| 2IL32UN | 0,6 | 0,6 | 2 | — 32 | — 2102653 |
| 3IL12UN | 1,1 | 1,4 | 3 | — 12 | — 2102749 |
| 3IL9UN | 1,2 | 1,7 | 3 | — 9 | — 3122446 |
| 3IL8UN | 1,1 | 1,5 | 3 | — 8 | — 3122444 |
