PGU

For grooving and parting operations, universal use. Positive chipbreaker groove for light cutting action. Right-hand and left-hand styles with 6° front angle.

left-hand neutral right-hand

PGM

width of cut [mm] 1 Recommended Starting Feed

For grooving and parting, also capable of copy and straight turning as well as chamfering. With additional chip forming element for good chip control with varying depths of cut.

neutral

PGS

width of cut [mm] 1 Recommended Starting Feed

left-hand neutral right-hand

PGR

For low-bur parting with straight fl anks and smooth surface fi nishes. All inserts are recommended for parting and grooving slender workpieces, part diameter <32mm, and thin-wall tubes.

width of cut [mm] 1 Recommended Starting Feed

Full round inserts for profi ling, grooving, and copy turning. Very good chip control for broad general use. Accurate, reproducible cutting edge positioning.

width of cut [mm] 1 Recommended Starting Feed

LG System • 0 and 1

…0 Inserts with wide range of applications in grooving and deep grooving. With additional chip control element for good chip control, even with varying widths of cut. …1 0 1 Inserts with wide range of uses in grooving and deep grooving of short chipping materials.

width of cut [mm] 1 Recommended Starting Feed
