Plunge and Contour Inserts
| -U-PC • Moulded | �first choice �alternate choice | P M K N S H | � � � � � � � � � � � � � � � � � � | |||
| catalogue number | seat size | W | RC | LI | WP10CT WP25CT WU10PT WU25PT WU10HT | |
| WMTR305M3UPC WMTR405M4UPC | 3 4 | 3,05 4,05 | 1,53 2,03 | 25,53 25,58 | 4170174 – 4170172 4170173 – 4170179 – 4170177 4170178 – | |
| WMTR505M5UPC WMTR605M6UPC | 5 6 | 5,05 6,05 | 2,53 3,03 | 29,01 28,77 | 4170184 – 4170182 4170183 – 4170189 – 4170187 4170188 – | |
| WMTR805M8UPC | 8 | 8,05 | 4,03 | 29,22 | 4170194 – 4170192 4170193 – |
