- Insert Screws
ISO
order number catalogue number Torx/hex internal thread
| 2840098 | MSM46 | 2 mm | M4X0.7 | |
| 2840186 | AS832/AS-8-32 | 5/64 | #8-32 | |
| 2892513 | BS832 | 5/64 | — | |
| 2820981 | LTM16 | T5 | M2X0.4 | |
| 2832647 | CC11 | T6 | #1-72 | |
| 2832635 | CT11 | T6 | #1-72 | |
| 2830477 | FC11 | T7 | — | |
| 2828337 | GT21 | T7 | #2-56 | |
| 2825941 | QTM20 | T7 | M2.5X0.45 | |
| 2825948 | QTM26 | T7 | M2.5X0.45 | |
| 2826005 | QC15 | T8 | #3-48 | |
| 2826038 | QC21 | T9 | #4-40 | |
| 2823227 | SC30 | T10 | #4-40 | |
| 2823203 | STM31 | T15 | M3.5 X 0.6 | |
| 2832641 | CT15 | T16 | #1-72 |
- Wrenches
ISO
order number catalogue number Torx/hex
| 2840094 | MKEY | 2.0 mm |
| 2840174 | AKEY | 5/64 |
| 2828318 | GTKEY | T5 |
| 2832628 | CKEY | T6 |
| 2830492 | FKEY | T7 |
| 2825973 | Q8KEY | T8 |
| 2825982 | QKEY | T9 |
| 2823182 | SKEY | T10 |
- Drive Bits
ISO
order number catalogue number Torx/hex
| 2840089 | MBIT | 2 mm |
| 2832661 | CBIT | T6 |
| 2830497 | FBIT | T7 |
| 2825963 | QTBIT | T7 |
| 2825964 | Q8BIT | T8 |
| 2826045 | QBIT | T9 |
| 2823236 | SBIT | T10 |
| 2823196 | STBIT | T15 |
- Wedges
ISO order number catalogue number 2840192 AW250/AW-250 2836024 BW312
