Quadralock™
Solid Carbide Inserts
P
M
first choice
K
alternate choice
N
S
H
MT
CM1
CG5
ISO
Tools for Small Hole Boring
catalogue number D min L4 L F CD W
right hand
2836180
MT09560F2R 2,79 7,93 24,44 1,17 0,56 0,05
–
2836328
3897497
MT12560F2R 3,56 9,53 26,04 1,55 0,69 0,05
2836168
MT15660F2R 4,45 12,70 29,21 1,93 0,81 0,05
–
left hand
3897493
3897494
MT09560F2L 2,79 7,93 24,44 1,17 0,56 0,05
3897496
3897495
MT12560F2L 3,56 9,53 26,04 1,55 0,69 0,05
3897498
3897499
MT15660F2L 4,45 12,70 29,21 1,93 0,81 0,05
widia.com D83
WID_Master16_Turning_Circle_D082_D083_Metric_REBRAND.indd 83 L V i WID M 16 T i Ci l D082 D083 M i REBRANDO b 15201510
10/30/15 29AM
3:20 PM
Solid Carbide Inserts
P
M
first choice
K
alternate choice
N
S
H
MT
CM1
CG5
ISO
Tools for Small Hole Boring
catalogue number D min L4 L F CD W
right hand
2836180
MT09560F2R 2,79 7,93 24,44 1,17 0,56 0,05
–
2836328
3897497
MT12560F2R 3,56 9,53 26,04 1,55 0,69 0,05
2836168
MT15660F2R 4,45 12,70 29,21 1,93 0,81 0,05
–
left hand
3897493
3897494
MT09560F2L 2,79 7,93 24,44 1,17 0,56 0,05
3897496
3897495
MT12560F2L 3,56 9,53 26,04 1,55 0,69 0,05
3897498
3897499
MT15660F2L 4,45 12,70 29,21 1,93 0,81 0,05
widia.com D83
