first choice alternate choice
- FNR-R/L
P M K N S H
ISO
| catalogue number | D | S | T | W | RC | D1 | ||
| right hand | ||||||||
| FNR150472R | 5,00 | 1,85 | 1,00 | 1,20 | 0,60 | 2,50 |
- CDT-R/L
ISO
| catalogue number | D | S | T | RC | D1 | TPI min | TPI max | TP min | TP max | ||||
| right hand | |||||||||||||
| CDT50022R | 3,97 | 1,27 | 0,76 | 0,05 | 2,11 | 24 | 48 | 0,5 | 1,0 |
- CPT-R/L
ISO
| catalogue number | D | S | T | RC | D1 | TPI min | TPI max | TP min | TP max | ||||
| right hand | |||||||||||||
| CPT20052R | 6,35 | 1,91 | 1,65 | 0,13 | 2,79 | 10 | 24 | 1,0 | 2,5 |
