to easily identify which attributes apply.
CDHBS4T002
| C | D | H | B | S4 | |||
| Insert Shape | Insert Clearance | Tolerance Class | Insert | Size |
Angle Features
Tolerances apply prior T 60° B to edge prep and coating. C 80°
C G 45° 45°
W 80°
D Rε Rε
Code for metric cutting edge length “L10” “D”
| mm | C | G | T | W |
| 3,97 | S4 | 05 | 06 | — |
| 4,06 | — | — | 07 | — |
| 4,76 | 04 | 06 | 08 | S3 |
| 6,35 | 06 | — | 11 | 04 |
| 9,53 | 09 | — | 16 | 06 |
| 9,80 | — | — | 17 | — |
P
Rε
D = Theoretical diameter of W the insert inscribed circle Partly cylindrical S = Thickness hole, 40–60° B = See fi gures below countersink, single-sided T
without chipbreaker
with chipbreaker
| tolerance | tolerance | tolerance | tolerance | without chipbreaker |
| class | on “D” | on “B” | on “S” | B |
| Partly cylindrical | ||||
| C | ±0,025 | ±0,013 | ±0,025 | hole, 70–90° |
| countersink, | ||||
| H | ±0,013 | ±0,013 | ±0,025 | |
| single-sided | ||||
| E | ±0,025 | ±0,025 | ±0,025 | with chipbreaker |
| H | ||||
| G | ±0,025 | ±0,025 | ±0,013 | |
| M | See tables on next page | ±0,013 | ||
| U | See tables on next page | ±0,013 |
