  • WK12PG TiCN for cast iron.

Shank Tolerance

Dtolerance h6
6+0, -0,008
8–10+0, -0,009
12–16+0, -0,011

„ GX35 Form E Bottoming Chamfer Through Coolant M6 and Larger Metric For Cast Iron

first choice alternate choice

grade WK12PGWK12PG TiCN metric dimensions

WK12PG grade WK12PG TiCN order # catalogue #D1 sizeLL3 meL2 tric dimensiLS onsDnumber of flutesclass of fit
5551152 GX352733M6 X 1701224426,046HX
5551153 GX352734M8 X 1,25801532438,046HX
5551154 GX352735M10 X 1,59018404410,046HX
5551156 GX352738M12 X 1,510021484612,046HX
5551155 GX352737M12 X 1,7510021484612,046HX
5551159 GX352740M14 X 1,511024565212,046HX
5551157 GX352739M14 X 211024565212,046HX
5551160 GX352741M16 X 211024644414,046HX
