  • WS32MG TiCN for nickel and nickel alloys.
Shank Tolerance
D mm tolerance h9
1–3 +0, -0,025
>3–6 +0, -0,030
>6–10 +0, -0,036
>10–18 +0, -0,043
>18–30 +0, -0,052

„ GT12 Form C Semi-Bottoming Chamfer Metric DIN 371 and 376 For Nickel and Nickel Alloys

first choice alternate choice

grade WS32MGWS32MG

WS3 grade T order #2MG WS32MG iCN catalogue #D1 sizeLL3 metric diL2 mensionsDnumber of flutesdimension standardclass of fit
4159636GT125001M3 X 0,55611183,52DIN 3716HX
4159637GT125002M4 X 0,76313214,53DIN 3716HX
4159638GT125003M5 X 0,87015256,03DIN 3716HX
4159639GT125004M6 X 18017306,03DIN 3716HX
4159640GT125005M8 X 1,259020358,03DIN 3716HX
4159641GT125006M10 X 1,5100223910,03DIN 3716HX
4159642GT125007M12 X 1,7511024—9,03DIN 3766HX
4159663GT125008M14 X 211026—11,03DIN 3766HX
4159664GT125009M16 X 211027—12,03DIN 3766HX
4159665GT125010M20 X 2,514032—16,03DIN 3766HX
