For information on L, L3, and L4 max, see page T143.
TDS402A • TDS412A • 5 x D
| D1 dia | meter | �firs �alte | it choice rnate cho | ice | |||||
| WP20PD grade WP20PD TiAlN | WK15PD grade WK15PD AlCrN | ||||||||
| order # catalogue # | order # catalogue # | mm | in | L | L3 | L4 max | L5 | LS | D |
| 4162967 TDS402A03000 | 4158757 TDS412A03000 | 3,000 | .1181 | 66 | 28 | 23 | 0,5 | 36 | 6 |
| 4162968 TDS402A03048 | 4158758 TDS412A03048 | 3,048 | .1200 | 66 | 28 | 23 | 0,5 | 36 | 6 |
| 4162969 TDS402A03100 | 4158759 TDS412A03100 | 3,100 | .1220 | 66 | 28 | 23 | 0,5 | 36 | 6 |
| 4162970 TDS402A03175 | 4158760 TDS412A03175 | 3,175 | .1250 | 66 | 28 | 23 | 0,5 | 36 | 6 |
| 4162972 TDS402A03200 | 4158761 TDS412A03200 | 3,200 | .1260 | 66 | 28 | 23 | 0,5 | 36 | 6 |
| 4162983 TDS402A03264 | 4158762 TDS412A03264 | 3,264 | .1285 | 66 | 28 | 23 | 0,5 | 36 | 6 |
| 4162984 TDS402A03300 | 4158793 TDS412A03300 | 3,300 | .1299 | 66 | 28 | 23 | 0,5 | 36 | 6 |
| 4162985 TDS402A03400 | 4158794 TDS412A03400 | 3,400 | .1339 | 66 | 28 | 23 | 0,6 | 36 | 6 |
| 4162986 TDS402A03455 | 4158795 TDS412A03455 | 3,455 | .1360 | 66 | 28 | 23 | 0,6 | 36 | 6 |
| 4162987 TDS402A03500 | 4158796 TDS412A03500 | 3,500 | .1378 | 66 | 28 | 23 | 0,6 | 36 | 6 |
| 4162988 TDS402A03571 | 4158797 TDS412A03571 | 3,571 | .1406 | 66 | 28 | 23 | 0,6 | 36 | 6 |
| 4162989 TDS402A03600 | 4158798 TDS412A03600 | 3,600 | .1417 | 66 | 28 | 23 | 0,6 | 36 | 6 |
| 4162990 TDS402A03658 | 4158799 TDS412A03658 | 3,658 | .1440 | 66 | 28 | 23 | 0,6 | 36 | 6 |
| 4162991 TDS402A03700 | 4158800 TDS412A03700 | 3,700 | .1457 | 66 | 28 | 23 | 0,6 | 36 | 6 |
| 4162992 TDS402A03734 | 4158801 TDS412A03734 | 3,734 | .1470 | 66 | 28 | 23 | 0,6 | 36 | 6 |
| 4162993 TDS402A03800 | 4158802 TDS412A03800 | 3,800 | .1496 | 74 | 36 | 29 | 0,6 | 36 | 6 |
| 4162994 TDS402A03900 | 4158803 TDS412A03900 | 3,900 | .1535 | 74 | 36 | 29 | 0,6 | 36 | 6 |
| 4162995 TDS402A03970 | 4158804 TDS412A03970 | 3,970 | .1563 | 74 | 36 | 29 | 0,7 | 36 | 6 |
| 4162996 TDS402A04000 | 4158805 TDS412A04000 | 4,000 | .1575 | 74 | 36 | 29 | 0,7 | 36 | 6 |
| 4162997 TDS402A04039 | 4158806 TDS412A04039 | 4,039 | .1590 | 74 | 36 | 29 | 0,7 | 36 | 6 |
| 4162998 TDS402A04090 | 4158807 TDS412A04090 | 4,090 | .1610 | 74 | 36 | 29 | 0,7 | 36 | 6 |
| 4162999 TDS402A04100 | 4158808 TDS412A04100 | 4,100 | .1614 | 74 | 36 | 29 | 0,7 | 36 | 6 |
| 4163000 TDS402A04200 | 4158809 TDS412A04200 | 4,200 | .1654 | 74 | 36 | 29 | 0,7 | 36 | 6 |
| 4163001 TDS402A04217 | 4158810 TDS412A04217 | 4,217 | .1660 | 74 | 36 | 29 | 0,7 | 36 | 6 |
