Series 47N6 VariMill I™ Extended Reach with Neck

  • Unequal flute spacing.
  • Centre cutting.
  • Single tool for both roughing and finishing operations requiring fewer setups.
  • Standard items listed. Additional styles and coatings made-to-order.

Detail X

„ Series 47N6 VariMill Extended Reach with Neck

End Mill Tolerances tolerance h6

D1tolerance e8D+ / -
) 3-0,014/-0,028) 30/-0,006
> 3-6-0,020/-0,038> 3–60/-0,008
> 6–10-0,025/-0,047> 6–100/-0,009
> 10–18-0,032/-0,059> 10–180/-0,011
> 18–30-0,040/-0,073> 18–300/-0,013

first choice alternate choice

grade TiAlN-LWTiAlN-LW TiAlN length of cut length

order # catalogue #D1DD3Ap1 maxL3LBCH
4067705 47N606002LW6,065,5012,0042,001000,40
4067706 47N608003LW8,087,3016,0062,001000,40
4067707 47N610004LW10,0109,1020,0060,001000,50
4067708 47N612005LW12,01211,0024,0073,001250,50
4067709 47N616006LW16,01614,5632,00100,001500,50
4067710 47N620007LW20,02018,2040,0098,001750,50
