| �MTJN 93° | L | 1 | F | |||||||
| order number | catalog number | mm | in | mm in | gage insert | shim | lock pin | clamp | clamp screw | kg lbs |
| 3902274 | right hand KM40TSMTJNR16 | 40 | 1.575 | 27 1.063 | TN..160408/TN..332 | ITSN322 | KLM34L | CKM7LP | STCM9 | 0,33 .73 |
| 3902275 | KM40TSMTJNR22 left hand | 40 | 1.575 | 27 1.063 | TN..220408/TN..432 | ITSN433 | KLM46 | CKM23LP | STCM11 | 0,36 .79 |
| 3902252 3902273 | KM40TSMTJNL16 KM40TSMTJNL22 | 40 40 | 1.575 1.575 | 27 1.063 27 1.063 | TN..160408/TN..332 TN..220408/TN..432 | ITSN322 ITSN433 | KLM34L KLM46 | CKM7LP CKM23LP | STCM9 STCM11 | 0,33 .73 0,36 .79 |
MTUN 93°
L1 F D min
gage lock clamp
| order number | catalog number | mm | in mm in mm in | insert shim | pin | clamp | screw | kg lbs | ||
| right hand | ||||||||||
| 3902278 | KM40TSMTUNR16 | 40 1.575 27 1.063 54 2.126 | TN..160408/TN..332 | ITSN322 | KLM34L | CKM7LP | STCM9 | 0,34 .76 | ||
| left hand | ||||||||||
| 3902276 | KM40TSMTUNL16 | 40 1.575 27 1.063 54 2.126 | TN..160408/TN..332 | ITSN322 | KLM34L | CKM7LP | STCM9 | 0,34 .76 | ||
| 3902277 | KM40TSMTUNL22 | 40 1.575 27 1.063 54 2.126 | TN..220408/TN..432 | ITSN433 | KLM46 | CKM20LP | STCM11 | 0,34 .75 |
