KM50TS Cutting Units KM50TS™ Cutting Units M-Clamping • M-Clamping Centerline MWLN 95° L1 F D min gage lock clamp order number catalog number mm in mm in mm in insert shim pin clamp screw kg lbs right hand 3738596 KM50TSMWLNR08 50 1.969 35 1.378 70 2.756 WN..080408/WN..432 IWSN433 KLM46 CKM20LP STCM11 0,64 1.41 left hand 3738595 KM50TSMWLNL08 50 1.969 35 1.378 70 2.756 WN..080408/WN..432 IWSN433 KLM46 CKM20LP STCM11 0,64 1.41 MCMN 50° • 95° Application • Centerline L1 F gage lock clamp order number catalog number mm in mm in insert shim pin clamp screw kg lbs 3738167 KM50TSMCMNN12 50 1.969 0 .000 CN..120408/CN..432 ICSN432 KLM46 CKM20 STCM11 0,47 1.03 NOTE: Use the KM63TSS5065 reducer to produce an L1 of 115mm. A128 WWW.WIDIA.COM
