Inserts • XNGU-ALP • For Aluminium and Other Non-Ferrous Alloys
v first choice j alternate choice
Back View
P M K N v S H
ISO cutting
| catalogue number | edges | LI | S | W | BS | Re | hm |
| XNGU100404ERALP | 4 | 11,66 | 4,83 | 6,60 | 1,37 | 0,40 | 0,02 |
XNGU100408ERALP 4 11,66 4,83 6,60 1,00 0,80 0,02
Inserts • XNGU-ML • Precision Finishing and Light Machining
v first choice j alternate choice P j j M v v
K j v
N Back View S v v H v
ISO cutting
| catalogue number | edges | LI | S | W | BS | Re | hm |
| XNGU100404ERML | 4 | 11,66 | 4,83 | 6,60 | 1,37 | 0,40 | 0,02 |
XNGU100408ERML 4 11,66 4,83 6,60 1,00 0,80 0,02
THE ALL-STAR PROGRAMME FEATURES ONLY THE MOST POPULAR PLATFORMS, GRADES, AND SIZES. FOR THE COMPLETE OFFERING, INCLUDING SPARE PARTS AND APPLICATION INFORMATION, VISIT WIDIA NOVO™ OR WIDIA.COM.
