Inserts • SNHX-ALP • For Aluminium and Other Non-Ferrous Alloys
v first choice j alternate choice
P M K N v S H
ISO cutting
| catalogue number | edges | LI | S | D | BS | Re |
| SNHX120408PNERALP | 8 | 12,00 | 4,61 | 12,00 | 1,34 | 0,80 |
Inserts • SNHX-ML • Precision Finishing and Light Machining
v first choice j alternate choice
| P | v j |
| M | v v |
| K | j |
| N | |
| S | v v |
H
ISO cutting
| catalogue number | edges | LI | S | D | BS | Re |
| SNHX120408PNERML | 8 | 12,00 | 4,61 | 12,00 | 1,34 | 0,80 |
Inserts • SNHX-MM • Universal Geometry for Medium Machining
v first choice j alternate choice P vvj M vvv
K v j v
N S vjv H v
ISO cutting
| catalogue number | edges | LI | S | D | BS | Re |
| SNHX120408PNSRMM | 8 | 12,00 | 4,61 | 12,00 | 1,34 | 0,80 |
