- Informational Icons Guide
- Material Overview • DIN
Weldon® End Mills • Metric
coolant
| order number | catalogue number | D1 | D | L | L2 | Ap1 max | Z | max RPM | supply | kg | |||
| 6596066 | VSM890D032Z03B25SN12 | 32 | 25 | 89 | 32 | 9,8 | 3 | 33200 | Yes | 0,31 |
Shell Mills • Metric
coolant
| order number | catalogue number D1 | D | D6 | L | Ap1 max | Z | max RPM | supply | kg | |
| 6596067 | VSM890D040Z04S22SN12 | 40 | 22 | 39 | 40 | 9,8 | 4 | 28000 | Yes | 0,20 |
| 6596069 | VSM890D050Z05S22SN12 | 50 | 22 | 49 | 40 | 9,8 | 5 | 24100 | Yes | 0,32 |
| 6596070 | VSM890D063Z05S22SN12 | 63 | 22 | 49 | 40 | 9,8 | 5 | 20800 | Yes | 0,48 |
| 6596111 | VSM890D063Z07S22SN12 | 63 | 22 | 49 | 40 | 9,8 | 7 | 20800 | Yes | 0,45 |
| 6596113 | VSM890D080Z07S27SN12 | 80 | 27 | 60 | 50 | 9,8 | 7 | 18000 | Yes | 1,03 |
| 6596114 | VSM890D080Z09S27SN12 | 80 | 27 | 60 | 50 | 9,8 | 9 | 18000 | Yes | 1,01 |
| 6596116 | VSM890D100Z08S32SN12 | 100 | 32 | 78 | 50 | 9,8 | 8 | 15800 | Yes | 1,56 |
| 6596119 | VSM890D125Z10S40SN12 | 125 | 40 | 89 | 63 | 9,8 | 10 | 13900 | Yes | 2,98 |
THE ALL-STAR PROGRAMME FEATURES ONLY THE MOST POPULAR PLATFORMS, GRADES, AND SIZES. FOR THE COMPLETE OFFERING, INCLUDING SPARE PARTS AND APPLICATION INFORMATION, VISIT WIDIA NOVO™ OR WIDIA.COM.
