| RR = RL | ||||||
| order number | catalogue number | grade | seat size | W (mm) | RR (mm) | LI (mm) |
| WMT-P-PH• Precis neutral | ion• Plunge, Groove, and Turn I | nserts | ||||
| 5346414 | WMTS300M3P03PH | WU10HT | 3 | 3,00 | 0,30 | 25,65 |
| 5346412 | WMTS300M3P03PH | WU10PT | 3 | 3,00 | 0,30 | 25,65 |
| 5346415 | WMTS300M3P06PH | WU10PT | 3 | 3,00 | 0,60 | 25,65 |
| 5346413 | WMTS300M3P03PH | WU25PT | 3 | 3,00 | 0,30 | 25,65 |
| 5346416 | WMTS300M3P06PH | WU25PT | 3 | 3,00 | 0,60 | 25,65 |
| 5346420 | WMTS400M4P03PH | WU10HT | 4 | 4,00 | 0,30 | 25,40 |
| 5346418 | WMTS400M4P03PH | WU10PT | 4 | 4,00 | 0,30 | 25,40 |
| 5346421 | WMTS400M4P06PH | WU10PT | 4 | 4,00 | 0,60 | 25,40 |
| 5346419 | WMTS400M4P03PH | WU25PT | 4 | 4,00 | 0,30 | 25,40 |
| 5346422 | WMTS400M4P06PH | WU25PT | 4 | 4,00 | 0,60 | 25,40 |
| 5346426 | WMTS500M5P03PH | WU10HT | 5 | 5,00 | 0,30 | 28,63 |
| 5346424 | WMTS500M5P03PH | WU10PT | 5 | 5,00 | 0,30 | 28,63 |
| 5346427 | WMTS500M5P06PH | WU10PT | 5 | 5,00 | 0,60 | 28,63 |
| 5346425 | WMTS500M5P03PH | WU25PT | 5 | 5,00 | 0,30 | 28,63 |
| 5346428 | WMTS500M5P06PH | WU25PT | 5 | 5,00 | 0,60 | 28,63 |
| 5346430 | WMTS600M6P03PH | WU10PT | 6 | 6,00 | 0,30 | 28,63 |
| 5346432 | WMTS600M6P06PH | WU10PT | 6 | 6,00 | 0,60 | 28,63 |
| 5346431 | WMTS600M6P03PH | WU25PT | 6 | 6,00 | 0,30 | 28,63 |
| 5346433 | WMTS600M6P06PH | WU25PT | 6 | 6,00 | 0,60 | 28,63 |
| order number | catalogue number | grade | seat size | W (mm) | RC (mm) | LI (mm) |
| WMT-U-PC• Mould | ed• Grooving and Profiling Ins | erts | ||||
| neutral | ||||||
| 4170172 | WMTR305M3UPC | WU10PT | 3 | 3,05 | 1,53 | 25,53 |
| 4170173 | WMTR305M3UPC | WU25PT | 3 | 3,05 | 1,53 | 25,53 |
| 4170177 | WMTR405M4UPC | WU10PT | 4 | 4,05 | 2,03 | 25,58 |
| 4170178 | WMTR405M4UPC | WU25PT | 4 | 4,05 | 2,03 | 25,58 |
| 4170182 | WMTR505M5UPC | WU10PT | 5 | 5,05 | 2,53 | 29,01 |
| 4170183 | WMTR505M5UPC | WU25PT | 5 | 5,05 | 2,53 | 29,01 |
| 4170187 | WMTR605M6UPC | WU10PT | 6 | 6,05 | 3,03 | 28,77 |
| 4170188 | WMTR605M6UPC | WU25PT | 6 | 6,05 | 3,03 | 28,77 |
| 4170189 | WMTR605M6UPC | WP10CT | 6 | 6,05 | 3,03 | 28,77 |
| 4170192 | WMTR805M8UPC | WU10PT | 8 | 8,05 | 4,03 | 29,22 |
| 4170193 | WMTR805M8UPC | WU25PT | 8 | 8,05 | 4,03 | 29,22 |
