D d c 1
| m7 | Dc | Lc | l1 | l2 | l5 | h6 | |
| Обозначение | мм | Дюймы | мм | мм | мм | мм | мм |
b
Хвостовик по DIN 6535 HA DC150-05-10.800A1- 10,8 56 118 71 45 12
b
| DC150-05-10.900A1- | 10,9 | 56 | 118 | 71 | 45 | 12 | |
| DC150-05-11.000A1- | 11 | 56 | 118 | 71 | 45 | 12 | b |
Dc d1 b
DC150-05-11.100A1- 11,1 56 118 71 45 12
L b
c DC150-05-11.113A1- 11,113 7/16“ 56 118 71 45 12
l2 l5 b
DC150-05-11.200A1- 11,2 56 118 71 45 12
l1 b
DC150-05-11.300A1- 11,3 56 118 71 45 12
b
DC150-05-11.400A1- 11,4 56 118 71 45 12
b
| DC150-05-11.500A1- | 11,5 | 56 | 118 | 71 | 45 | 12 | ||
| DC150-05-11.509A1- | 11,509 | 29/64“ | 56 | 118 | 71 | 45 | 12 | b |
b
DC150-05-11.600A1- 11,6 56 118 71 45 12
b
| DC150-05-11.700A1- | 11,7 | 56 | 118 | 71 | 45 | 12 | |
| DC150-05-11.800A1- | 11,8 | 56 | 118 | 71 | 45 | 12 | b |
| DC150-05-11.900A1- | 11,9 | 56 | 118 | 71 | 45 | 12 | b |
b
| DC150-05-11.906A1- | 11,906 | 15/32“ | 56 | 118 | 71 | 45 | 12 | |
| DC150-05-12.000A1- | 12 | 56 | 118 | 71 | 45 | 12 | b | |
| DC150-05-12.100A1- | 12,1 | 60 | 124 | 77 | 45 | 14 | b |
b
| DC150-05-12.200A1- | 12,2 | 60 | 124 | 77 | 45 | 14 | |
| DC150-05-12.250A1- | 12,25 | 60 | 124 | 77 | 45 | 14 | b |
| DC150-05-12.300A1- | 12,3 | 60 | 124 | 77 | 45 | 14 | b |
b
DC150-05-12.303A1- 12,303 31/64“ 60 124 77 45 14
b
| DC150-05-12.400A1- | 12,4 | 60 | 124 | 77 | 45 | 14 | |
| DC150-05-13.100A1- | 12,4 | 60 | 124 | 77 | 45 | 14 | b |
b
DC150-05-12.500A1- 12,5 60 124 77 45 14
b
| DC150-05-12.600A1- | 12,6 | 60 | 124 | 77 | 45 | 14 | ||
| DC150-05-12.700A1- | 12,7 | 1/2“ | 60 | 124 | 77 | 45 | 14 | b |
| DC150-05-12.800A1- | 12,8 | 60 | 124 | 77 | 45 | 14 | b |
b
| DC150-05-12.900A1- | 12,9 | 60 | 124 | 77 | 45 | 14 | |
| DC150-05-13.000A1- | 13 | 60 | 124 | 77 | 45 | 14 | b |
| DC150-05-13.200A1- | 13,2 | 60 | 124 | 77 | 45 | 14 | b |
b
| DC150-05-13.300A1- | 13,3 | 60 | 124 | 77 | 45 | 14 | ||
| DC150-05-13.400A1- | 13,4 | 60 | 124 | 77 | 45 | 14 | b | |
| DC150-05-13.494A1- | 13,494 | 17/32“ | 60 | 124 | 77 | 45 | 14 | b |
b
DC150-05-13.500A1- 13,5 60 124 77 45 14
b
| DC150-05-13.600A1- | 13,6 | 60 | 124 | 77 | 45 | 14 | |
| DC150-05-13.700A1- | 13,7 | 60 | 124 | 77 | 45 | 14 | b |
b
DC150-05-13.800A1- 13,8 60 124 77 45 14
b
| DC150-05-13.900A1- | 13,9 | 60 | 124 | 77 | 45 | 14 | |
| DC150-05-14.000A1- | 14 | 60 | 124 | 77 | 45 | 14 | b |
| DC150-05-14.100A1- | 14,1 | 63 | 133 | 83 | 48 | 16 | b |
b
| DC150-05-14.200A1- | 14,2 | 63 | 133 | 83 | 48 | 16 | ||
| DC150-05-14.288A1- | 14,288 | 9/16“ | 63 | 133 | 83 | 48 | 16 | b |
| DC150-05-14.300A1- | 14,3 | 63 | 133 | 83 | 48 | 16 | b |
b
| DC150-05-14.500A1- | 14,5 | 63 | 133 | 83 | 48 | 16 | |
| DC150-05-14.600A1- | 14,6 | 63 | 133 | 83 | 48 | 16 | b |
| DC150-05-14.700A1- | 14,7 | 63 | 133 | 83 | 48 | 16 | b |
b
DC150-05-14.750A1- 14,75 63 133 83 48 16
b
| DC150-05-14.800A1- | 14,8 | 63 | 133 | 83 | 48 | 16 | |
| DC150-05-15.000A1- | 15 | 63 | 133 | 83 | 48 | 16 | b |
b
DC150-05-15.100A1- 15,1 63 133 83 48 16
b
| DC150-05-15.200A1- | 15,2 | 63 | 133 | 83 | 48 | 16 | |
| DC150-05-15.300A1- | 15,3 | 63 | 133 | 83 | 48 | 16 | b |
| DC150-05-15.500A1- | 15,5 | 63 | 133 | 83 | 48 | 16 | b |
b
| DC150-05-15.600A1- | 15,6 | 63 | 133 | 83 | 48 | 16 | ||
| DC150-05-15.700A1- | 15,7 | 63 | 133 | 83 | 48 | 16 | b | |
| DC150-05-15.800A1- | 15,8 | 63 | 133 | 83 | 48 | 16 | b | |
| DC150-05-15.875A1- | 15,875 | 5/8“ | 63 | 133 | 83 | 48 | 16 | b |
Пример заказа инструмента из сплава WJ30RE: DC150-05-03.000A1-WJ30RE Продолжение
