Fe atu re s - Trepanning To o ls
Outer thread type
Various insert options
A range of chipbreakers and
grades are available for materials
STS connection
Customized connections
are also available. Please
contact your dealer for
further information.
Cartridges allow Sub guide pad
fine adjustments
Controls the drill head movement
of tool diameter
in the guide bushing
5 6 5 3 4 6 2
| 5 | 5 | 7 | |||
| 7 | |||||
| 3 | 4 | 1 | |||
| 4 | 2 |
| 4 | 3 | 3 | |||
| 1 | 3 | ||||
| 6 |
3 4 5
4 5 Part positions may vary depending on the drill size.
Inner thread type
Optimized positions of
| STS connection | guide pads and inserts |
| Customized connections | In order to maintain the tool’s |
| are also available. Please | dynamic balance during |
| contact your dealer for | machining, the inserts and |
| further information. | guide pads are optimally |
| positioned on the drill body. | |
| Also, to streamline inventory | |
| management, all cartridges and | |
| related parts of the Trepanning | |
| Guide pad protector Series are commonized and |
can be interchanged. Protects guide pad from damage when retracting tool after drilling 5
6 5 3 4 6 2
| 5 | 5 | 7 | |||
| 7 | |||||
| 3 | 4 | 1 | |||
| 4 | 2 |
4 3 3
Part positions may vary depending on the drill size.
