EndmillsSquareRadiusBallnoseMulti-PurposeGeneral-purposeHighEfficiencyHardene dSteelRoughingNon-ferrousMetalCFRPCoatedUncoated -0.040 DC -0.060 Stock DMM h6 -0.040 DC -0.060 ap DMM h6 Solid Carbide Endmills for Non-Ferrous Metals ASM 2000 Type Aluminum CopperAlloyAlloy Corner Uncoated Flutes Carbide Helix Angle Side Milling Grooving Groove Finishing Face Milling Spot Facing Helical Milling Ramping Fig 1 Fig 2 APMX APMX LU θ LF LF DC θ < ø3 10° I ≥ ø3 < ø6 15°> ø620° Body Dimensions (mm) Cat. No. Dia.DC Cutting Edge Length Neck Length Overall LengthAPMXLULF Shank Dia.DMM Fig ASM 2020 ● 2.0 6 6.8 40 4 1 ASM 2030 ● 3.0 10 12.9 45 6 1 ASM 2040 ● 4.0 12 14.7 45 6 1 ASM 2050 ● 5.0 15 18.6 50 6 1 ASM 2060 ● 6.0 15 ― 50 6 2 ASM 2080 ● 8.0 18 ― 60 8 2 ASM 2100 ● 10.0 22 ― 71 10 2 ASM 2120 ● 12.0 25 ― 75 12 2 ASM 2140 ● 14.0 32 44.2 90 16 1 ASM 2150 ● 15.0 32 44.1 90 16 1 ASM 2160 ● 16.0 32 ― 90 16 2 Grade: H1 Recommended Cutting Conditions 1. If the machine cannot achieve the standard spindle speed, please use the maximum spindle speed available. 2. If cutting noise and vibration occur, please reduce the cutting conditions accordingly. ae Side Milling Work MaterialCuttingAluminum Alloy Cast IronSpecial Cast Iron Conditions DC (mm) Spindle Speed Feed Rate Spindle Speed Feed Rate(min-1)(mm/min)(min-1)(mm/min) 2.0 35,000 460 13,000 240 3.0 23,400 770 8,750 275 4.0 17,500 800 6,550 310 6.0 11,700 910 4,370 340 8.0 8,750 980 3,280 390 10.0 7,000 1,100 2,620 400 12.0 5,850 1,150 2,185 430 16.0 4,380 1,150 1,640 430 Standard ap 1.5DC 1.5DC Depth of Cut ae 0.1DC 0.1DC I96
