DC Stock DMM h6 DC DMM h6 UncoatedCoatedCFRPNon-ferrousMetalRoughingHardenedSteelHighEfficiencyGeneral-purposeMulti-PurposeBallnoseRadiusSquareEndmills Solid Carbide Spiral Endmills SSM 2000 Type General Carbon Cast Iron AluminumSteelSteelAlloy Corner Uncoated Flutes Carbide Helix Angle Side Milling Groove Finishing Fig 1 Fig 2 APMX θLU APMX LF LF DC θ DC Tolerance < ø3 10° D ≤ 6.0 -0.010 -0.030 ≥ ø3 < ø6> ø6 15° 6.0 < D ≤ 10.0 -0.015 -0.04020°10.0 < D-0.020-0.050I Body (Diameter ø4.7 to 9.1mm) Dimensions (mm) Cat. No. Dia.DC Cutting Edge Length Neck Length Overall LengthAPMXLULF Shank Dia.DMM Fig SSM 2047 ● 4.7 12.0 18.0 50 6 1 SSM 2048 ● 4.8 12.0 18.2 50 6 1 SSM 2049 ● 4.9 12.0 18.4 50 6 1 SSM 2050 ● 5.0 12.0 18.6 50 6 1 SSM 2051 ● 5.1 12.0 18.3 50 6 1 SSM 2052 ● 5.2 12.0 18.5 50 6 1 SSM 2053 ● 5.3 12.0 18.6 50 6 1 SSM 2054 ● 5.4 12.0 18.8 50 6 1 SSM 2055 ● 5.5 12.0 19.0 50 6 1 SSM 2056 ● 5.6 12.0 19.2 50 6 1 SSM 2057 ● 5.7 12.0 19.4 50 6 1 SSM 2058 ● 5.8 12.0 19.6 50 6 1 SSM 2059 ● 5.9 12.0 19.8 50 6 1 SSM 2060 ● 6.0 12.0 ― 50 6 2 SSM 2061 ● 6.1 12.0 16.3 50 8 1 SSM 2062 ● 6.2 12.0 16.5 50 8 1 SSM 2063 ● 6.3 12.0 16.6 50 8 1 SSM 2064 ● 6.4 12.0 16.8 50 8 1 SSM 2065 ● 6.5 12.0 16.9 50 8 1 SSM 2066 ● 6.6 15.0 23.0 55 8 1 SSM 2067 ● 6.7 15.0 23.2 55 8 1 SSM 2068 ● 6.8 15.0 23.3 55 8 1 SSM 2069 ● 6.9 15.0 23.4 55 8 1 SSM 2070 ● 7.0 15.0 23.6 55 8 1 SSM 2071 ● 7.1 15.0 23.7 55 8 1 SSM 2072 ● 7.2 15.0 23.9 55 8 1 SSM 2073 ● 7.3 15.0 24.0 55 8 1 SSM 2074 ● 7.4 15.0 24.1 55 8 1 SSM 2075 ● 7.5 15.0 24.3 55 8 1 SSM 2076 ● 7.6 15.0 23.9 55 8 1 SSM 2077 ● 7.7 15.0 24.0 55 8 1 SSM 2078 ● 7.8 15.0 24.2 55 8 1 SSM 2079 ● 7.9 15.0 24.3 55 8 1 SSM 2080 ● 8.0 15.0 ― 55 8 2 SSM 2081 ● 8.1 15.0 22.2 55 10 1 SSM 2082 ● 8.2 15.0 22.5 55 10 1 SSM 2083 ● 8.3 15.0 22.6 55 10 1 SSM 2084 ● 8.4 15.0 22.8 55 10 1 SSM 2085 ● 8.5 15.0 22.9 55 10 1 SSM 2086 ● 8.6 15.0 23.0 55 10 1 SSM 2087 ● 8.7 15.0 23.2 55 10 1 SSM 2088 ● 8.8 15.0 23.3 55 10 1 SSM 2089 ● 8.9 15.0 23.4 55 10 1 SSM 2090 ● 9.0 15.0 23.6 55 10 1 SSM 2091 ● 9.1 15.0 23.7 55 10 1 Grade: A1 I65
