EndmillsSquareRadiusBallnoseMulti-PurposeGeneral-purposeHighEfficiencyHardene dSteelRoughingNon-ferrousMetalCFRPCoatedUncoated Stock DC DMM h6 Solid Carbide Spiral Endmills SSM 2000 Type General Carbon Cast Iron AluminumSteelSteelAlloy Corner Uncoated Flutes Carbide Helix Angle Side Milling Groove Finishing Fig 1 APMX θ LU LF DC θ DC Tolerance < ø3 10° D ≤ 6.0 -0.010 -0.030 I ≥ ø3 < ø6 15° 6.0 < D ≤ 10.0 -0.015 -0.040> ø620°10.0 < D-0.020-0.050 Body (Diameter ø0.2 to 4.6mm) Dimensions (mm) Cat. No. Dia.DC Cutting Edge Length Neck Length Overall LengthAPMXLULF Shank Dia.DMM Fig SSM 2002 ● 0.2 0.5 0.5 40 3 1 SSM 2003 ● 0.3 1.0 1.0 40 3 1 SSM 2004 ● 0.4 1.0 1.0 40 3 1 SSM 2005 ● 0.5 1.5 1.5 40 3 1 SSM 2006 ● 0.6 1.5 1.5 40 3 1 SSM 2007 ● 0.7 1.5 1.5 40 3 1 SSM 2008 ● 0.8 2.0 2.0 40 3 1 SSM 2009 ● 0.9 2.0 2.0 40 3 1 SSM 2010 ● 1.0 3.0 3.9 40 4 1 SSM 2011 ● 1.1 3.0 4.2 40 4 1 SSM 2012 ● 1.2 3.0 4.0 40 4 1 SSM 2013 ● 1.3 3.0 4.3 40 4 1 SSM 2014 ● 1.4 3.0 4.1 40 4 1 SSM 2015 ● 1.5 5.0 5.9 40 4 1 SSM 2016 ● 1.6 5.0 6.1 40 4 1 SSM 2017 ● 1.7 5.0 5.9 40 4 1 SSM 2018 ● 1.8 5.0 6.2 40 4 1 SSM 2019 ● 1.9 5.0 6.0 40 4 1 SSM 2020 ● 2.0 6.0 6.8 40 4 1 SSM 2021 ● 2.1 6.0 7.1 40 4 1 SSM 2022 ● 2.2 6.0 6.8 40 4 1 SSM 2023 ● 2.3 6.0 7.1 40 4 1 SSM 2024 ● 2.4 6.0 6.9 40 4 1 SSM 2025 ● 2.5 8.0 8.7 40 4 1 SSM 2026 ● 2.6 8.0 9.0 40 4 1 SSM 2027 ● 2.7 8.0 8.8 40 4 1 SSM 2028 ● 2.8 8.0 9.0 40 4 1 SSM 2029 ● 2.9 8.0 8.8 40 4 1 SSM 2030 ● 3.0 8.0 12.9 45 6 1 SSM 2031 ● 3.1 8.0 12.0 45 6 1 SSM 2032 ● 3.2 8.0 12.2 45 6 1 SSM 2033 ● 3.3 8.0 12.4 45 6 1 SSM 2034 ● 3.4 8.0 12.6 45 6 1 SSM 2035 ● 3.5 8.0 12.8 45 6 1 SSM 2036 ● 3.6 10.0 14.0 45 6 1 SSM 2037 ● 3.7 10.0 14.2 45 6 1 SSM 2038 ● 3.8 10.0 14.3 45 6 1 SSM 2039 ● 3.9 10.0 14.5 45 6 1 SSM 2040 ● 4.0 10.0 14.7 45 6 1 SSM 2041 ● 4.1 10.0 14.4 45 6 1 SSM 2042 ● 4.2 10.0 14.6 45 6 1 SSM 2043 ● 4.3 10.0 14.8 45 6 1 SSM 2044 ● 4.4 10.0 15.0 45 6 1 SSM 2045 ● 4.5 10.0 15.2 45 6 1 SSM 2046 ● 4.6 12.0 17.8 50 6 1 Grade: A1 I64
